• Model NO.：FD160
• Lift height：3500mm
• Condition：New
• Tyre：Double Front Tires
• Weight：21000kg
• Engine：Yuchai
• Wheelbase：3600mm
• Color：Customized
• Mast Tilt Angle：6,12
• Item Name：16 Ton Diesel Forklift
• Free Lift：180mm
• Fork Size (L*W*H)：1800X200X90mm
• Min. Ground Clearance：270mm
• Transport Package：Container
• Specification：7200mm*2750mm*3500mm
• Trademark：LTMG
• Origin：China
• HS Code：84272090
• Production Capacity：300set,Years

GeneralManufacture LTMGModel FD160Power type DieselRated capacityKg16000Load centermm600
DimensionsLift heightmm3000Free lift heightmm100Fork sizemm1600*180*90Fork distanceMin./Max.mm680/1700Mast tilt angle deg8/12Front overhangmm1050Overall dimensionsLength to face of forkmm7200Overall widthmm2750Mast lowered heightmm3500Mast extended heightmm5220Overhead guard heightmm3220Turning radiusmm5050Min.right angle aisle widthmm3712Performance no load/full loadTravel speadKm/h30/22Lifting speadmm/sc300/240Max.grade ability%20Max.Pull force(full load)KN110Service weightkg21000ChassisTyresFront 4*12.00-24*18PRRear 2*10.00-20*16PRTreadFrontmm1850Rearmm1820Wheelbasemm3200Min.Ground clearance( no load/full load)Mastmm250/240Framemm250/240Drive unit & controlBatteryV/AH24/100*2Engine Model YC6B125-T21Manufacture YUCHAIRated outputkW/rpm 129/2300Rated torqueN.m/rpm450/1300-1400No.of cylinder 6Bore*strokemm 108*125DisplacementL6.871Fuel tank capacityL300TransmissionsType HydraulicShift Front/rear 2/1
