Ltmg Forklift Price 7 Ton Diesel Forklift Truck with Hydraulic System

Xiamen LTMG Machinery Co., Ltd.
  • Warranty：1 Year or 2000 Working Hours
  • Cab Location：Not Adjustable
  • Type：Powered Pallet Truck
  • Power：Diesel Engine
  • Load Capacity：7 Ton
  • Fuel：Diesel

Base Info

  • Model NO.：FD70
  • Load center：600mm
  • Lift height：3000~5000mm
  • Condition：New
  • Engine：Isuzu,Xichai
  • Fork Size：1220mm*150mm*65mm
  • Weight：9450kg
  • Wheelbase：2250mm
  • Color：Decided by Buyer
  • Overall Length：3590mm
  • Max. Lifting Height：3000mm
  • Truck Weight：9450kg
  • Rated Power：112kw,2000rpm
  • Transport Package：Nude Packing, Fixed in Container
  • Specification：3590mm*1995mm*2500mm
  • Trademark：LTMG
  • Origin：China
  • HS Code：84272090
  • Production Capacity：800sets,Year

Description

LTMGModel Power shift T/MFD70Load capacity kg7000Load center mm600Power unit  DieselOperator type  Driver/seatTire typeFront/rear PneumaticWheelFront/rear 4/2Max. lifting height mm3000Free lift mm210Fork sizeL*W*Tmm1220*150*65Tilt rangeMast forward/backwarddeg6/12Overall length mm3590Total width mm1995Mast height (fork lowering) mm2500Overall height fork raisedWith backrestmm4420Height to head guard mm2450Turning radius(outside) mm3360Front face of fork to front axle mm620Min. right angle stacking aislewithout load length& clearancemm5620SpeedMax Travelling   full/no loadkm/h26/30Lifting full/no loadmm/s450/550Lowering full/no loadmm/s450/500Max.drawbar pullfull/no loadkg5400/2200Gradeability at 1.6km/hfull load%29Max. Gradeabilityfull/no load%33/19Truck weight kg9450Weight  distributionFull load front/rearkg14520/1930No load front/rearkg3760/5690TiresNumberfront/rear4/2Modelfront axle8.25x15-14PRrear axle8.25x15-14PRWheelbase mm2250TreadFront/rearmm1470/1700At lowest point(mast)mm190Ground clearanceFramemm230BrakeService brake Brake boosterParking brake Mechanical-handBatteryVoltage/capacityV/AH2x12V-80AHEngineModel ISUZU 6BG1Xichai 6110Rated powerPS(kw/rpm)112/2000110/2500Rated torqueg-m max.(N.m)42.5/150036/1650Number of cylinders 66PlacementL6.4945.785Fuel tank capacityL140TransmissionSpeed forward/backwardPower shift T/M Manual shift T/M2-2 power shift T/M
