• Model NO.：CDD*B
• Fuel：Electric
• Load center：500mm
• Lift height：3000~5000mm
• Condition：New
• Wheel Type：Polyurethane
• Service Parking：Electromagnetic
• Drive Motor：1.5kw
• Lift Motor：2.2kw
• Battery Type：Lead Acid
• Battery V/Ah：24V,210ah
• Drive Motor Type：AC
• Transport Package：Pallet
• Specification：Electric forklift
• Trademark：CHEESON
• Origin：China
• HS Code：8427109000
• Production Capacity：5000sets,Year

Basic Info.

Model NO. CDD*B Fuel Electric Load center 500mm Lift height 3000~5000mm Condition New Wheel Type Polyurethane Service Parking Electromagnetic Drive Motor 1.5kw Lift Motor 2.2kw Battery Type Lead Acid Battery V/Ah 24V/210ah Drive Motor Type AC Transport Package Pallet Specification Electric forklift Trademark CHEESON Origin China HS Code 8427109000 Production Capacity 5000sets/Year

Product Description

Electric Pallet Stacker (CDD*B)(Counterbalanced Type)

01 CURTIS electronic control, multiple automatic protection system controller.

02 Without frequent adjustment, the damping spring can actively adjust the vertical driving unit according to the road conditions, reduce the impact on the driving unit, balance the force on the driving balance wheel, and improve the smooth operation efficiency.

03 High quality hydraulic system with buffer, low noise, small vibration, good sealing, stable and reliable lifting and lowering.

04 AC drive, no carbon brush, maintenance free, efficient motor, precise control, strong power output.

05 As a standard configuration, the emergency power-off switch can cut off all the power supply by pressing the emergency stop button. The car stops immediately or cuts off power quickly in case of emergency, providing safety protection.

06 Multi functional handle, integrated control (acceleration, horn, emergency anti-collision, lifting button), human-machine design and operation more comfortable.

07  Wide view design of gantry, special channel steel, high strength.
