• Model NO.：CQD*E
• Fuel：Electric
• Load center：500mm
• Lift height：1600~12000mm
• Condition：New
• Operate Type：Seated
• Forward Distance：480,650,610mm
• Fork Size：35,100,1070mm
• Driving Speed(Unload/Load)：7.8,6.8 Km,H
• Lifting Speed (Unload/Load)：0.24,0.12 M,S
• Drive Motor：4.5 Kw
• Lift Motor：6.3 Kw
• Battery V/Ah：48V,300ah
• Transport Package：Pallet
• Specification：Electric Reach Stacker
• Trademark：CHEESON
• Origin：China
• HS Code：8427109000
• Production Capacity：5000sets,Year

Basic Info.

Model NO. CQD*E Fuel Electric Load center 500mm Lift height 1600~12000mm Condition New Operate Type Seated Forward Distance 480/650/610mm Fork Size 35/100/1070mm Driving Speed(Unload/Load) 7.8/6.8 Km/H Lifting Speed (Unload/Load) 0.24/0.12 M/S Drive Motor 4.5 Kw Lift Motor 6.3 Kw Battery V/Ah 48V/300ah Transport Package Pallet Specification Electric Reach Stacker Trademark CHEESON Origin China HS Code 8427109000 Production Capacity 5000sets/Year

Product Description

01 CURTIS electronic control, the controller is equipped multiple automatic protection system.
02 EPS steering energy consumption is reduced by 20%.It is precise to operate, which can reduce driver fatigue, and greatly improve the productivity.
03 Electric reach truck is suitable for large tonnage and high hoisting cargo storage. It applies to a variety of pallets. It has the characteristics of moving forward for the entire gantry, and the turning radius is small, which can neglect obstacles from the bottom of the shelf. It is suitable for narrow channel.
04 When the lifting control lever is in a safe lowering position, the lowering speed of the fork automatically slows down when it drops to 10cm from the ground, effectively preventing the goods from being damaged due to vibration.When the fork rises to the highest position, the buffer system reduces the gantry vibration and it improves the operator's comfort.
05 The power-off switch on the pedal controls the operation of the vehicle. Only after the pedal power-off switch is depressed can the vehicle be operated, otherwise the vehicle stops driving. The design improves the safety performance of the vehicle.
06 48V high power battery, long endurance and battery life.
