• Model NO.：SH30FR
• Lift height：3000~5000mm
• Condition：New
• Load Capacity (T)：3t
• Power Type：Gasoline,LPG
• Lifting Height：3000mm
• Fork Length：1220mm
• Transport Package：Container, LCL,FCL
• Specification：CE
• Trademark：sinoheng
• Origin：Shandong China
• Production Capacity：300PCS,Month

Product NameCounterbalance Gasoline /LPG Powered Forklift Truck(FR series )ModelSH30FRLoad capacity (kg)3000Load center (mm)500Power typeGasoline/LPGMax. lifting speeds ( with load )  mm/s400Max. driving speeds ( with/without load )  km/h18/20Max. towing ( with/without load )  kn15,5/10,5Gradeability (with/without load )  %15/20Lifting height (mm)3000Free lift (mm)80Tilting angles ( forward-backward )  (  .)6/12Min. turning radius (mm)2500Min. right angle aisel width ( mm )2110Min. under-clearance (mm)135
DimensionOverall length (including fork)mm3800Overall width ( mm )1230Overall height (mast lowered )mm2110Overall height (mast extend )mm4270Overall height to overhead guard (mm)2110Fork overhang (mm)465Wheel base (mm)1700TreadFront tread (mm)                   1000Rear tread (mm)970TyreFront tyre28 x 9-15Rear tyre6,50-10Total weight (kg)4320Fork width (mm)125Fork thickness (mm)45Backrest height (mm)1225Fork length (mm)                   1220

EngineEngine modelMITSUBISHI 4G64-31ZG/CHINESE GQ4YRate power (KW)37/36Rotate speed at Rate power (rpm)2650/2400Max. torque  (nm)≥148Rotate speed at max torque (rpm)1800-1900Type of power shiftTor-non
