500kg Mini Forklift Battery (Electric) Forklift Made in China Cpd500
Jinan Sinoheng Import and Export Co., Ltd.- Type：Powered Pallet Truck
- Power：DC Motor
- Load Capacity：≤1T
- Fuel：Electric
- Load center：300mm
- Lift height：2000mm
Base Info
- Model NO.：CPD500
- Condition：New
- Power Type：Electric
- Rated Load：500kg
- Max. Lifting Height：2000mm
- Lift Speed：480,460mm,S
- Machine Weight：725kg
- Overall Dimension：1450*742*1580mm
- Fork Length：1070mm
- Fork Width：93mm
- Max.Extend Width：700mm
- Input Voltage：220V
- Transport Package：Polywood Box
- Specification：CE, ISO9001: 2000
- Trademark：SINOHENG
- Origin：Shandong, China
- Production Capacity：500PCS , Week
Description
Model
CPD500
Power type
Electric
Operating mode
Seated type
Rated load
500kg
Max. lifting height
2000mm
Min. turning radius
1200mm
Door frame tilt angle
6/12 degree
Lift speed
480/460mm/s
Down speed
400mm/s
Driving speed
12km/h
Load center distance
300mm
Turned way
Electric power(Mechanical)
Machine weight
725kg
Lifting motor power
2kw
Drive motor power
1.5kw
Motor brake
Front wheel foot brake
Min ground clearance
90mm
Overall dimension
1450*742*1580mm
Fork length
1070mm
Fork width
93mm
Max.extend width
700mm
Wheel base
890mm
wheel tread
620/580
Front tyre size
15*4½-8
Rear tyre size
3.50-5
Battery
12v/170ah * 4
Working time for one charge
Less than 8h
Input voltage
220v
Charging time
8/10h
