• Model NO.：FEP15
• Lift height：120mm
• Condition：New
• Weight：286kg
• Fork Size：1150mm*160mm*47mm
• Warranty：1 Year,2000 Working Hours
• Color：Customize
• Lifting Height (Standard)：120mm
• Turning Radius：1460mm
• Pump Stations：24V,0.8kw
• Drive Motor：24V,0.75kw
• Battery：2*12V,65ah
• Total Length(Pedal Down)：1620mm
• Transport Package：Container
• Specification：1620*685*1174mm
• Trademark：LTMG
• Origin：China
• HS Code：8427109000
• Production Capacity：800sets,Year

modelunitFEP13FEP15Rated loadkg13001500Fork widthmm560/685560/685Fork lengthmm11501150Minimum fork heightmm8585Maxmum fork heightmm200200Turning radiusmm14601460Load Centermm600600Pump stations 24V/0.8Kw24V/0.8KwDrive motor 24V/0.75Kw24V/0.75KwBattery 2*12V/65Ah2*12V/65AhWeight(without battery)kg200(163)220(170)Total length(pedal down)mm16201620Overrall widthmm560/685560/685Total heightmm11741174


Features
1.Safety: Auto Curve Speed-reduced function;
2.Anti-roll back prevents uncontrolled traveled speed or roll-back on ramps when loading and unloading;
3.The small ground clearance, to protect the operator;
4.High-strength frame design, suitable for tough workplaces, ensures longer service life;
5.Vertical motor ensures convenience inspection and maintenance of motor and brake, provide much better maintainability than horizontal motor.

LTMG Factory




LTMG Clients





After sales service

LTMG always treat after-sale as important as sale.Nowadays more than 50 agents around the world can supply LTMG professional after-sale service.

All the product of LTMG supplied with 1 year or 2000 working hours(which occurs first)period quality warranty.
Detail clauses and policies please check our website and product certificate.
