• Model NO.：FD20
• Lift height：3000-6000
• Condition：New
• Transmission Type：Auto Electric Hydraulic Transmission
• Hydraulic System：Japanese Hydraulic System
• Steering Gear Type：USA Eaton Steering Gear
• Title Cylinder Anti-Dust Protection：Yes
• Color：Red,Yellow,Green,Customized
• Mast Type：Duplex 3m, Triplex Full Free 4.5m,6m
• Engine Model：Chinese Xinchai Engine, Japanese Isuz, Mitsubishi
• Tool Box：Included
• Side Shifter：Can Be Customized
• Paper Roll Clamp：Can Be Customized
• Transport Package：Nude Package,Container Delivery
• Specification：2570*1175*2120 mm
• Trademark：SNSC
• Origin：China
• HS Code：84272090
• Production Capacity：500units,Month

mast typelifting heightstandard duplex mast3m-4mduplex full free mast3m-4mtriplex full free mast3.6m/4m/4.5m/5m/5.5m/6m/7m







Specifications of SNSC forklift 2ton diesel forklift truck                                         FD20 FORKLIFT SPECIFICATIONSNo.SpecificationsUnitFD2011CharacteristicsPower diesel22Rated Capacitykg200033Center of loadmm50044Lifting heightmm300055Free lifting heightmm13566Forks L×W×Hmm1070x122x4077Tilt Forward/Backward.6/1288Min.turning radiusmm224099Min.ground clearance(Mast)mm1101010Overhead guard heightmm21201111Height from seat to overhead guardmm9431212Front overhangmm4731313PerfMax.traveling speed(loaded)km/h191414Max.lifting speed(loaded/empty)mm/s470/5101515Drawbar pull/GradeabilitykN/%17/201616DimensionsOverall length (without fork)mm25701717Overall widthmm11751818Mast lowered height mm19901919Mast extended heightmm40002020ChassisTireFront 7.00-12-12PR2121Rear 6.00-9-10PR2222Wheelbasemm16002323Tread widthFront/Rearmm970/9702424Curb weightNone-loadkg33502525PowertrainBatteryVoltage/CapacityV/Ah12/902626EngineModel XC490BPG2727Rated powerkw/r.p.m37/26502828Rated torqueNm/r.p.m148/20002929Cylinder amount 43030Bore×Stroke mm90x1003131Displacement 2.543232Fuel tankL603333Transmission 1/1 automatic transmission3434Working pressureMPa17.5

Packing and delivery
Our 2ton DIESEL forklift can be delivered by container or ro-ro shipment.
One 20'GP containr can hold 3 units 2tons diesel forklifts;
one 40'GP container can hold 6 units 2ton diesel engine forklift trucks.


Related SNSC forklift products:
Our SNSC forklifts have different forklift series that can meet our customer's different needs.
1. Counter Balanced Diesel powered forklift truck range from 1.5 to 10ton;(FD30,FD35,FD40,FD45,FD50,FD60,FD70)
2. Battery powered electric forklift truck range from 1.5 to 3.5ton;
(FB15, FB20, FB25, FB30, FB35)
3. Counter Balanced LPG and gasoline powered dual fuel forklift trucks range from 1.5 to 3.5 ton;
(FL15, FL18, FL20, FL25, FL30, FL35)
4. warehouse equipments, like electric pallet truck, electric reach truck, electric stacker & electric trailer, scissor lift, double deep electric reach truck, racks.

If you have interests in our 2ton diesel forklift, welcome you to contact Nicole.
