• Model NO.：CPCY50
• Fuel：Diesel
• Load center：>500mm
• Lift height：>5000mm
• Condition：New
• Engine：Cummins
• Transport Package：by Container
• Specification：CCC, ISO, SGS
• Trademark：Haiqin
• Origin：Shandong, China
• HS Code：84271090
• Production Capacity：8000 Units , Year

OverviewModel of driving powerDieselRated load5000kgLoad center distance500mmLifting height3000mm / 4500mm

Performance
SpeedRunning speed (no load)22Km/hLifting speed(full load)300 mm /sMax. grade ability20 °Dead weight9500kg

TiresTiresFront wheel11.00-20Rear wheel16/70-20TreadFront wheel1575mmRear wheel1545mmWheelbase2185mmMin ground clearance285mm




Driving power and transmissionBatteryVoltage24V


EngineModelCUMMINS 4BTA3.9-C100Place of OriginXiangyang HubeiOutput power74 KWRated torque410Number of cylinders4Cylinder size X tripn.aDisplacementn.aFuel tank capacity40LTransmissionGear(front and rear)2/2Work pressure16 Mpa


2,, Certificate of Haiqin Machinery:





3, Warranty and Service.

HAIQIN Forklift has One Year Warranty.
During Warranty, if there is any part broken because of quality problem(except easy-damaged parts), send us detailed pictures and video, then we will send good/ new parts for your replacements.

Choose HAIQIN, and then better after-service will be guaranteed.

Contact us right now for more information!  Online 24 hours a day!
