• Model NO.：FD35
• Lift height：3000-6000
• Condition：New
• Transmission Type：Auto Electric Hydraulic Transmission
• Engine Model：Chinese Xinchai Engine, Japanese Isuz, Mitsubishi
• Hydraulic System：Japanese Hydraulic System
• Mast Type：Duplex 3m, Triplex Full Free 4.5m,6m
• Radiator Type：Copper Radiator
• Steering Gear：USA Eaton Brand
• Side Shifter：Can Be Customized
• Solid Tire：Can Be Customized
• Block Clamp：Can Be Customized
• Color：Red,Yellow,Green,Customized
• Forklift Attachment：Can Be Customized
• Transport Package：Nude Package,Container Delivery
• Specification：2825*1230*2170 mm
• Trademark：SNSC
• Origin：China
• HS Code：84272090
• Production Capacity：500units,Month

mast typelifting heightstandard duplex mast3m-4mduplex full free mast3m-4mtriplex full free mast3.6m/4m/4.5m/5m/5.5m/6m/7m





Specifications of SNSC 3.5ton diesel forklift truck
This is our standard 3.5ton diesel forklift techincal specifications.
We also can customized the fork lifter according to our customer's demands and working conditions.SNSC FD35 FORKLIFT SPECIFICATIONSNo.SpecificationsUnitFD3511CharacteristicsPower diesel22Rated Capacitykg350033Center of loadmm50044Lifting heightmm300055Free lifting heightmm14566Forks L×W×Hmm1070×125×4577Tilt Forward/Backward.6/1288Min.turning radiusmm260099Min.ground clearance(Mast)mm1201010Overhead guard heightmm21701111Height from seat to overhead guardmm4801212Front overhangmm5451313PerfMax.traveling speed(loaded)km/h201414Max.lifting speed(loaded/empty)mm/s470/5201515Drawbar pull/GradeabilitykN/%18/201616DimensionsOverall length (without fork)mm38951717Overall widthmm12301818Mast lowered height mm20951919Mast extended heightmm42652020ChassisTireFront 28×9-15-12PR2121Rear 6.50-10-10PR2222Wheelbasemm18002323Tread widthFront/Rearmm1000/9702424Curb weightNone-loadkg44502525PowertrainBatteryVoltage/CapacityV/Ah12/902626EngineModel QC490GP2727Rated powerkw/r.p.m39/26502828Rated torqueNm/r.p.m157/19802929Cylinder amount 43030Bore×Stroke mm90×1053131Displacement 2.673232Fuel tankL703333Transmission1/1 automatic transmission3434Working pressureMPa17.5

Our Factory Strength
We, SNSC  fork lifter factory, are top 3 fork lifter montacargas manufactures and top 20 in the world. with 130,000 square meters production area, over 500 employees,30,000 units forklifter diesel truck production capacity per year,5000 sets export volume.
We are big fork lifter manufacture not small maker. We are responsible for our customers and forklifters.
''QUALITY LEADING THE FUTURE" is our belief for ever.
We'd like to offer our best quality forklift to our customers from all over the world.


SNSC brand FD35 3.5tons DIESLE MOTOR powered FORKLIFT TRUCK shipment solutions:
Our 3.5ton DIESEL forklift can be delivered by container or ro-ro shipment.
One 20'GP containr can hold 2 units 3.5tons diesel forklifts;
one 40'GP container can hold 4 units 3.5ton diesel engine forklift trucks.

Related SNSC forklift products:
Our SNSC forklifts have different forklift series that can meet our customer's different needs.
1. Counter Balanced Diesel powered forklift truck range from 1.5 to 10ton;(FD30,FD35,FD40,FD45,FD50,FD60,FD70)
2. Battery powered electric forklift truck range from 1.5 to 3.5ton;
(FB15, FB20, FB25, FB30, FB35)
3. Counter Balanced LPG and gasoline powered dual fuel forklift trucks range from 1.5 to 3.5 ton;
(FL15, FL18, FL20, FL25, FL30, FL35)
4. warehouse equipments, like electric pallet truck, electric reach truck, electric stacker & electric trailer, scissor lift, double deep electric reach truck, racks.

If you have interests in our 3.5ton diesel forklift, welcome you to contact Nicole
