Ltmg 10ton Articulated Rough Terrain Forklift with Side Shift Fork Positioner Air conditioner
XIAMEN LTMG CO., LTD.- Warranty：1 Year
- Cab Location：Optional
- Type：Diesel Forklift
- Power：Diesel Engine
- Load Capacity：10ton
- Fuel：Diesel
Base Info
- Model NO.：LTR100
- Load center：500mm
- Lift height：3000~5000mm
- Condition：New
- Item Type：2WD,4WD Rough Terrain Forklift
- Engine：Cummins
- Rated Capacity：10000kg
- Min.Ground Clearance：360mm
- Wheel Base：2630mm
- Max.Grade Ability：20%
- Work Pressure：16 MPa
- Output Power：92kw
- Transport Package：Container
- Specification：8000kg
- Trademark：LTMG
- Origin：China
- HS Code：84272090
- Production Capacity：1000units,Year
Description
Rated Power
10000 Kg
Rated center distance
500 mm
Running speed(no load)
21 Km/h
Lifting speed(full load)
490 Km/h
Max.grade ability
20%
Deadweight
8000 Kg
Tires
Front wheel
17.5-25
Rear wheel
17.5-25
Tread
Front wheel
1800 mm
Rear wheel
1800 mm
Wheelbase
2630 mm
Min.ground clearance
360 mm
Battery
Voltage
24V
Engine
Model
CA110/125G5
Place of origin
Xichai
Output power
92 Kw
Rated torque
432 Nm
Number of cylinders
6
Cylinder size X trip
90 X 100 mm
Displancement
2540 cc
Fuel tank capacity
65 L
Transmission
Gears(front and rear)
3/2
Work pressure
16 Mpa
