• Model NO.：FD40
• Lift height：3000~5000mm
• Condition：New
• Rated Loading Capacity：4000kg
• Max. Lifting Height：3000mm
• Fork Length：1070mm
• Forkwidth：122mm
• Engine：Quanchai Isuzu
• Transport Package：Nude Package
• Specification：3500*1150*2150mm
• Trademark：ZOOMLION
• Origin：Anhui, China
• HS Code：8430691100
• Production Capacity：100pieces,Month

SpecificationsUnitFD40(mechanical )FD45(mechanical )FD45FD50(Mini)CharacteristicsPower dieseldieseldieseldieselRated Capacitykg4000450045005000Center of loadmm500500500500Lifting heightmm3000300030003000Free lifting heightmm146146146146Forks L×W×Hmm1070×150×501070×150×501070×150×501070×150×50Tilt Forward/Backward.6/126/126/126/12Min.turning radiusmm2760276027602800Min.ground clearance(Mast)mm160160160160Overhead guard heightmm2350235023502350Height from seat to overhead guardmm1040104010401040Front overhangmm558558565565PerfMax.traveling speed(loaded)km/h18181818Max.lifting speed(loaded/empty)mm/s380/400380/400410/430410/430Drawbar pull/GradeabilitykN/%22/2022/2022/2022/20DimensionsOverall length (without fork)mm3060306030603100Overall widthmm1490149014901490Mast lowered height mm2355235523552355Mast extended heightmm4257425742574257ChassisTireFront 8.25-15-14PR8.25-15-14PR300-15-18PR300-15-18PRRear 7.00-12-12PR7.00-12-12PR7.00-12-12PR7.00-12-12PRWheelbasemm2000200020002000Tread widthFront/Rearmm1180/11901180/11901180/11901180/1190Curb weightNone-loadkg6090632063806600PowertrainBatteryVoltage/CapacityV/Ah(12/90)×2(12/90)×2(12/90)×2(12/90)×2EngineModel XC 4D35GXC 4D35GQC 4JR3QC 4JR3Rated powerkw/r.p.m48/230048/230060/220060/2200Rated torqueNm/r.p.m230/1600-1800230/1600-1800300/1600-1800300/1600-1800Cylinder amount 4444Bore×Stroke mm98x11598x115108×135108×135DisplacementL3.473.474.954.95Fuel tankL100100100100Transmission 2/2 mechanical transmission1/1 automatic transmissionWorking pressureMPa18.518.518.518.5



Our service:
