• Model NO.：XT550CD
• Lift height：3000~5000mm
• Condition：New
• Fork Size L*W*T：1220*150*55mm
• Fork Regulating Range Min/Max：300,1845mm
• Gantry Angle：6°,12°
• Front Overhang：580mm
• Rear Overhang：600mm
• Transport Package：Comply with Export Packaging Requirements
• Specification：ISO
• Trademark：XCMG
• Origin：Xuzhou, Jiangsu, China
• HS Code：84272090
• Production Capacity：10000,Year

ModelXT530CNominal Weight3000kgLoad Center Distance500mmLift height3000mmFree lift height165mmFork size L*W*T1070*125*45mmFork regulating range min/max250/1100mmGantry angle6°/12°DegFront overhang485mmRear overhang520mmDoor frame ground clearance140mmOverall dimensionsBody length(without fork)2685mmOverall width1210mmMast lowered height2075mmMast extended height(with backnest)4100mmOverhead guard height2170mmTurning radius2430mmMin right angle stacking aisle width(add load length and clearance)2140mmspeedSpeed(unladen)19Km/hLifting speed (laden)430Mm/secDecreased speed(laden)450Mm/secMax.drawdar pull(laden/unladen)17/15knMax.gradeability(laden)20%tirefront28*9-15-14PRmmrear6.50-10-10PRmmtreadfront1000mmrear980mmwheelbasa1700mmweight4310kgWeight distributionladenfront6290kgrear1020kgunladenfront1940kgrear2370kgBattery voltage/capacity12/90V/AhenginemodelC490BPG manufacture  Rated power/speed40/2650kwRated torque156/1700-1900N.mNo.of cylinder4 Bore*stroke90*105mmdiplacement2/2.67LFuel tank capacity70LtransmmisionmanufactureCHINA type( Stage front/rear1/1(2/2 operating17.5Mpa
