• Model NO.：FD50
• Lift height：3000~5000mm
• Condition：New
• Engine Modelt ：Lr4b3-G88
• Rated Power：57kw,2200r.p.m
• Mast Height：4260mm
• Fork Sizetl*W*T：1070*150*50mm
• Forklift Load Center：600mm
• Transport Package：Nude Packaging
• Specification：3060*1480*2240mm
• Trademark：ZOOMLION
• Origin：Anhui, China
• HS Code：8501109190
• Production Capacity：50000units,Year

Model

FD50

Features

Power type

Diesel

Rated Load

kg

5000

Load Center

mm

600

Fork Size

L*W*T

mm

1070×150×50

Mast Tilt Radius

Front/Rear

.

6/12

Dimension

Overall Length

Without Fork

mm

3060

Overall Width

mm

1480

Max. Fork Lifting height (With Load Backrest)

mm

2240

Mast Height

mm

4260

Chassis

Tyre

Front

300-15-18PR

Rear

7.00-12-12PR

Wheel Base

mm

2000

Power

Battery

Voltage/Capacity

V/Ah

(12/90)x2

Engine

Model

LR4B3-G88

Rated Power

kw/r.p.m

57/2200

Rated Torque

Nm/r.p.m

285/1300-1500

Bore*Stroke

mm

108 ×125

Cylinder Amount

4

Displacement

L

4.58
