• Model NO.：ESR10-60
• Load Capacity：1T - 5T
• Fuel：Electric
• Load center：>500mm
• Lift height：3000~5000mm
• Condition：New
• Brake Type：Electromagnetic
• Battery Voltage：24V
• Battery Capacity：280ah
• Controller：Curtis
• Wheel Base：1584mm
• Fork Dimension：35*100*920
• Service Weight：1220kg
• Overall Length：3026mm
• Overall Width：856mm
• Drive Motor(AC)：1.5kw
• Lift Motor(DC)：2.2kw
• Power Source：Battery
• Transport Package：Nude Packing
• Trademark：GP
• Origin：China
• HS Code：842720900
• Production Capacity：5000
• Package size per unit product：302.60cm * 85.60cm * 105.00cm
• Gross weight per unit product：880.000kg

Basic Info.

Model NO. ESR10-60 Load Capacity 1T - 5T Fuel Electric Load center >500mm Lift height 3000~5000mm Condition New Brake Type Electromagnetic Battery Voltage 24V Battery Capacity 280ah Controller Curtis Wheel Base 1584mm Fork Dimension 35*100*920 Service Weight 1220kg Overall Length 3026mm Overall Width 856mm Drive Motor(AC) 1.5kw Lift Motor(DC) 2.2kw Power Source Battery Transport Package Nude Packing Trademark GP Origin China HS Code 842720900 Production Capacity 5000

Packaging & Delivery

Package size per unit product 302.60cm * 85.60cm * 105.00cm Gross weight per unit product 880.000kg

Product Description

Features:

1) Electronic power steering system, light and low noise

2) Drive unit floating bodies wigh patent design

3) AC driving system, no carbon brush, maintenance free

4)USA CURTIS controller, German REMA handler, imported waterproof electrical components

5)Electromagnetic braking system

6)Stepless speed control system

7)Controller with multiple automatic protection

8)Integrated hydraulic and power control system, easily operation, reliable performance

9)Emergency reversing device/ emergency brake switch

10)Brake effect when handler at highest and lowest position.

11)More safety with double limit switch when lift

12)Small turning radius, reliable work with lower load center

13)Mast tilt function, Hydraulic system self-rock function
