• Model NO.：ESC115
• Lift height：3000~5000mm
• Condition：New
• Brake Type：Electromagnetic
• Battery Voltage：24V
• Battery Capacity：210ah
• Controller：Curtis
• Wheel Base：1500mm
• Fork Dimension：35*100*920
• Service Weight：1582kg
• Overall Length：3050mm
• Overall Width：856mm
• Forklift Height：3000-6000mm
• Drive Motor(AC)：1.5kw
• Lift Motor(DC)：2.2kw
• Transport Package：Nude Packing
• Trademark：GP
• Origin：China
• HS Code：842720900
• Production Capacity：1000

Basic Info.

Model NO. ESC115 Lift height 3000~5000mm Condition New Brake Type Electromagnetic Battery Voltage 24V Battery Capacity 210ah Controller Curtis Wheel Base 1500mm Fork Dimension 35*100*920 Service Weight 1582kg Overall Length 3050mm Overall Width 856mm Forklift Height 3000-6000mm Drive Motor(AC) 1.5kw Lift Motor(DC) 2.2kw Transport Package Nude Packing Trademark GP Origin China HS Code 842720900 Production Capacity 1000

Product Description

Features:

1) Electronic power steering system, light and low noise

2) Drive unit floating bodies wigh patent design

3) AC driving system, no carbon brush, maintenance free

4)USA CURTIS controller, German REMA handler, imported waterproof electrical components

5)Electromagnetic braking system

6)Stepless speed control system

7)Strong drive enforce, big greadability, safe and reliable

8)Controller with multiple automatic protection

9)Integrated hydraulic and power control system, easily operation, reliable performance

10)Emergency reversing device/ emergency brake switch

11)Brake effect when handler at highest and lowest position.
