• Model NO.：CPCY35
• Lift height：3000~5000mm
• Condition：New
• Engine：Xinchai 490
• Lifting Height：3m to 6m
• Standard Mast：2-Stage
• Fork Length：1220mm
• Transport Package：Nude
• Specification：3.5ton
• Origin：China
• HS Code：84272090
• Production Capacity：500PCS,Month

Basic Info.

Model NO. CPCY35 Lift height 3000~5000mm Condition New Engine Xinchai 490 Lifting Height 3m to 6m Standard Mast 2-Stage Fork Length 1220mm Transport Package Nude Specification 3.5ton Origin China HS Code 84272090 Production Capacity 500PCS/Month

Product Description

3.5T Rough terrain  4WD  forklift  with CE and EPA

Product Description

Xinchai 490 model 40 kw diesel engine or Yarmar 42.1KW EPA tire 3
Two ways valves, Automatic transmission.
1.22 meter fork length. Cabin with air heater.
Duplex mast 3 meter lifting height.
Rated load 3.5 tons.
Dead weight: 4230kgs
20 Feet container 1 unit.
40 feet container 3 units.
(Note: This is container inside operation and four wheel drive model)

Certificate: ISO,CE

Model	CPCY 35
Rated load (kg)	3500
Lifting height (mm)	3000
Load centre	500
Without Pallet fork  Length (mm)	3655
Width (mm)	1700
Max. height To the cab top (mm)	2170
Mast Tilt Angle(Front/Rear)	6/12
Wheelbase (mm)	2080
Tread	1170
Tyres	12-16.5 (14PR)
Self weight	4230
Battery Voltage/Capacity	24 V ( 80ahx2 )
Standard Engine brand	XINCHAI
Standard engine model	C490 BPG
Standard engine power (kw)	40
Transmission	Automatic 2F/2R
Unload Max speed (km/H)	28
Max. Gradeability (Laden) %	22
Fork size L×W×T (mm)	1220*125*50
Min. ground clearance(drive steer axle)(mm)	260
Turning radius (mm)	4760
