3.5t Gasoline/LPG Forklift Truck

Jiangsu Gather Power Industry Co., Ltd.
  • Cab Location：Adjustable
  • Type：Heavy Forklift
  • Power：Gasoline Engine
  • Load Capacity：1T - 5T
  • Fuel：Gasoline
  • Load center：>500mm

Base Info

  • Model NO.：CPQD35
  • Lift height：3000~5000mm
  • Condition：New
  • Fork Size(L*W*T)：1070*120*40mm
  • Mast Tilt Angle(Deg)：6,12
  • Turning Radius：2200mm
  • Self Weight：4000kg
  • Battery(V/Ah)：12,100
  • Transport Package：Standard Packing
  • Specification：2700*1200*2000mm
  • Trademark：GP
  • Origin：Shanghai
  • Production Capacity：5000 Pieces Per Year

Description

Modle CPQYD35Power type LPG/GasRated Capacitykg3500Load Centremm500Lift Height mm3000Fork sizemm1070*120*40Mast Tile Angle F/RDeg6/12Front Overhangmm470Ground Clearancemm120Length to face of Forkmm2600Overall widthmm1150Mast Lowered Heightmm2055Mast Extended Height(backrest)mm4050Overhead Guard Heightmm2070Turning Radiusmm2310Min.insecting aislemm2380speed travel(Empty)km/h19speed Lifting(full load)mm/s530Max Gradeability%20 front Tire 7-12-12PRRear Tire 6-9-10PRWheelbasemm1600Service weightmm3700BatteryV/Ah12/80Engine Modle K25Manufacture NISSIANEngine Rated output/r.p.mkw37.4/2300Engine Rated torque/r.p.mN.m176.5/1600No.of Cylinder 4Bore. STROKEmm89*100Displacementcc2488Fuel Tank CapacityL60Type HydraulicTransimission stage 1/1Operating Pressure for AttachmentMpa17.53.5t Gasoline/LPG Forklift Truck3.5t Gasoline/LPG Forklift Truck3.5t Gasoline/LPG Forklift Truck
3.5t Gasoline/LPG Forklift Truck
