Gp High Quality and Hot Sale Semi-Electric Stacker with 1000kg Load Capacity (TA10T)

Jiangsu Gather Power Industry Co., Ltd.
  • Type：Stacker
  • Power：DC Motor

Base Info

  • Model NO.：TA10T
  • Load Capacity：≤1T
  • Fuel：Electric
  • Load center：500mm
  • Lift height：3000~5000mm
  • Condition：New
  • Fork Length：1000mm
  • Fork Width：300-680mm
  • Min.Turning Radius：1350,1450mm
  • Max.Fork Height：2000,2500,3000,3500mm
  • Lifting Motor：12,1.5-1.6 V,Kw
  • Aneroid Battery：12,120-150 V,Ah
  • Charger：12,15 V,a
  • Overall Net Weight：425-500kg
  • Transport Package：Standard Package
  • Specification：1660*810*1830mm
  • Trademark：GP
  • Origin：China
  • Production Capacity：50000pieces,Year
  • Package size per unit product：166.00cm * 81.00cm * 183.00cm
  • Gross weight per unit product：500.000kg

Description

Semi-Electric Stacker Model
ItemSpecificationTA10T-20TA10T-25TA10T-30TA10T-35TA15T-20TA15T-25TA15T-30TA15T-35TA20T-201Rate capacity   kg1000150020002Load center        mm4003Max. fork height  mm2000250030003500200025003000350020004Max.machine heightmm2560306035604060256030603560406025605Fork lengthmm10006Fork widthmm300-6807Min.turning radius  mm135014501350145013508Wheel  basemm11859Front- wheel distancemm31610Lifting motorv/kw12/1.5-1.611Aneroid batteryv/Ah12/120-15012Chargerv/A12/1513Overall length  mm166014Overall widthmm81093081093081015Overall  heightmm15801830208023301580183020802330158016Overall net weightkg425450470500450475495520470
