• Model NO.：FD200
• Load center：>500mm
• Lift height：3000~5000mm
• Condition：New
• Engine：Shangchai
• Rated Power/Rotate Speed：160,2200kw,R.Pm
• Fork Size：2000mm*260mm*100mm
• Weight：28000kg
• Color：Decided by Buyer
• Min. Ground Clearance：250mm
• Wheelbase：4000mm
• Mast Tilt Angle (Front/Rear)：6,12degree
• Mast Lifting Height：3500mm
• Transport Package：Nude Packing, Flat Rack
• Specification：8790mm*3020mm*3600mm
• Trademark：LTMG
• Origin：China
• HS Code：84272090
• Production Capacity：800sets,Year

ModelUnitFD250TRated load 25000Load center 1250Free liftMm180Mast tilt angle (front/rear)º6/12Overall dimensionsLengthMm9190WidthMm3020HeightMm3610Mast lifting heightMm3500Fork size (L*W*H)Mm2440X280X110Min.Turning radiusMm6600Max.Travel speed (with load)Km/h28Lifting speed (with load)Mm/s180Gradeability (with load)%20WeightKg32000Front 4X14.00-24/28PRRear 2X14.00-24/28PRWheel treadFrontMm2200RearMm2390WheelbaseMm4400Min.Ground clearanceMm250Model WD10G220Rated power/rotate speedKW/r.Pm162/2200Max.Torque/rotate speedN.M/r.Pm850/1450Product Features

1.Engine:Weichai Engine, strong power, energy conservation and environmental protection.
Steering system:Adopt transverse oil cylinder type steering bridge, full-hydraulic steering, flexible and light, reliable.

2.Transmission & torque converter:Imported technology, reliable performance, convenient maintenance, smooth transmission, and convenient operation.

3.Braking system:Use mature product from professional manufacturer, disc brakes, heat dissipation faster, light, simple structure and easy to adjust.Especially have very good thermostability performance when heavy loaded, braking effect stable.

4.Explosion proof safety valve for pipeline:Avoid the pipeline bursting suddenly,ensure system working safety and reliability.

5.Control system:Pilot valve control device to make the work efficiency and reduce drivers' labor intensity.
Fork:Standard with hydraulic fork positioner, easy operation and reduce drivers' labor intensity.
Mast:Box-type internal-external mast, special all-round roller bearings, increase lifting performance.

6.Cab:Smooth and beautiful appearance, the cab uses new composite decoration materials, and match with air-conditioner, more open vision.




LTMG machinery is engaged in forklift industry over 20 years.We produce a wide range of forklifts, loaders and airport tractors


Customers Show/Application Show
Our LTMG Forklift is widely used in the port, wharf, industrial and mining enterprises, station, warehouse, and others.
The quality of our LTMG forklift has been recognized by our customers.



After sales service

Nowadays we have been sell more than 60 countries.
All the products of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
Detail clauses and policies please see to our website and product's quality certificate.
