• Model NO.：FD100
• Lift height：3000-6000
• Condition：New
• Radiator Type：Copper Radiator
• Mast Type：Duplex 3m, Triplex Full Free 4.5m,6m
• High Position Exhaust：Yes
• Tyre Type：Double Front Pneumatic Tires
• Screw Fork Positioner：Yes
• Transmission Type：Auto Electric Hydraulic Transmission
• Side Shifter：Can Be Customized
• Hydraulic System：Japanese Shimadzu Brand Hydraulic Pump
• Double Air Filter：Yes
• Engine Model：Chinese Xinchai Engine, Japanese Isuz, Mitsubishi
• Transport Package：Nude Package,Container Delivery
• Specification：4260*2230*2850 mm
• Trademark：SNSC,customize
• Origin：China
• HS Code：84272090
• Production Capacity：500units,Month

SNSC  FD100 FORKLIFT SPECIFICATIONSNO.SpecificationsunitFD1001CharacteristicsPower diesel2Rated Capacitykg100003Center of loadmm6004Lifting heightmm30005Free lifting heightmm2206Forks L×W×Hmm1220×175×807Tilt Forward/Backward.6/128Min.turning radiusmm39009Min.ground clearance(Mast)mm25010Overhead guard heightmm260011Height from seat to overhead guardmm109012Front overhangmm71513PerfMax.traveling speed(loaded)km/h2614Max.lifting speed(loaded/empty)mm/s290/35015Drawbar pull/GradeabilitykN/%57/2016DimensionsOverall length (without fork)mm426017Overall widthmm223018Mast lowered height mm285019Mast extended heightmm433520ChassisTireFront 9.00-20-14PR21Rear 9.00-20-14PR22Wheelbasemm280023Tread widthFront/Rearmm1600/170024Curb weightNone-loadkg1250025PowertrainBatteryVoltage/CapacityV/Ah(12/90)x226EngineModel XC611027Rated powerkw/r.p.m83/200028Rated torqueNm/r.p.m450/145029Cylinder amount 630Bore×Stroke mm110×12531Displacement 7.12732Fuel tankL14033Transmission1/1 automatic transmission34Working pressureMPa20

Our Strong Factory Capacity
We, ZOOMLION/SNSC  fork lifter factory, are top 3 fork lifter montacargas manufactures and top 20 in the world. with 130,000 square meters production area, over 500 employees,30,000 units forklifter diesel truck production capacity per year,5000 sets export volume.
We are big fork lifter manufacture not small maker. We are responsible for our customers and forklifters.
''QUALITY LEADING THE FUTURE" is our belief forever.
We'd like to offer our best quality fork lifters to our customers from all over the world.



Related SNSC forklift products
1. Counter Balanced Diesel powered forklift truck range from 1.5 to 10ton;(FD30,FD35,FD40,FD45,FD50,FD60,FD70,FD80,FD100)
2. Battery powered electric forklift truck range from 1.5 to 3.5ton;
(FB15, FB20, FB25, FB30, FB35)
3. Counter Balanced LPG and gasoline powered dual fuel forklift trucks range from 1.5 to 3.5 ton;
(FL15, FL18, FL20, FL25, FL30, FL35)
4. warehouse equipments, like electric pallet truck, electric reach truck, electric stacker & electric trailer, scissor lift, double deep electric reach truck, racks.


If you have interests in our forklift, welcome you to contact Nicole
