Electric Pallet Truck 2tons Stacker
Jinan Shine International Trade Co., Ltd.- Cab Location：Not Adjustable
- Type：Stacker
- Power：AC Motor
- Load Capacity：1T - 5T
- Fuel：Electric
- Load center：600mm
Base Info
- Model NO.：DB20
- Lift height：2500-5000mm
- Condition：New
- Lifting Height：2500-5000mm
- Controller：USA Curtis Brand Controller
- Mast Type：Duplex Mast, Triplex Full Free Mast
- Battery Power：24V,285ah
- Fork Length：1150mm
- Outside Fork Width：570,685mm
- Charger：Included
- Color Choice：Red,Yellow,Green
- Turning Type：Electric Turning
- Operation Type：Stand-on It
- Transport Package：Ship Delivery, Nude Package
- Specification：2054 x 850 x 2030 mm
- Trademark：SNSC
- Origin：China
- HS Code：8427109000
- Production Capacity：500units, Month
Description
Characteristics1.1 model DB12-R1 DB16-R1 DB20-R1 1.2 drive battery 1.3 operator type Stand-on 1.4 load capacity Q(kg) 1200 1600 2000 1.5 load centre c(mm) 600 1.6 front overhang x(mm) 651 701 1.7 wheel base Y(mm) 1275 1325 weight 2.1 capacity(with battery) kg 1260 1340 2.2 axle loading ,unladen(front/rear) kg 860/1600 1140/1800 1260/2080 2.3 axle loading ,laden(front/rear) kg 820/440 920/420 920/420 wheels chassis 3.1 tyres type polyurethane 3.2 wheel size (front) φ230×75 3.3 wheel size (rear) φ80×93 φ80×70 3.4 additional wheels φ125×50 3.5 wheels ,number front/rear (x = drven wheels) 1x+2/2 1x+2/4 3.6 track width (front) b10(mm) 620 3.7 track width (rear) b11(mm) 385/500 500 dimentions 4.1 ciosed mast height h1(mm) 2030 4.2 lifting height h3(mm) 3000 4.3 height ,mast extended h4(mm) 3550 4.4 height of tiller in driving position min/max h14(mm) 1042/1410 4.5 height ,fork lowered h13(mm) 86 90 4.6 length l1(mm) 2054 4.7 length to face of forks l2(mm) 904 4.8 width b1(mm) 850 4.9 fork dimentions s/e/l(mm) 60/185/1150 4.10 width across forks b5(mm) 570/685 685 4.11 ground clearance centre of wheelbase m2(mm) 29 4.12 aisel width,pallet 1000x1200(1200crossways) Ast(mm) 2465 2504 4.13 aisel width,pallet 800x1200(1200lengthways) Ast(mm) 2398 2437 4.14 turning radius Wa(mm) 1559 1598 Dimensions 5.1 travel speed ,laden/unladen Km/h 5/5.5 5.2 lifting speed laden/unladen m/s 0.1/0.15 0.13/0.18 0.08/0.12 5.3 lowering speed , laden/unladen m/s 0.08/0.18 0.13/0.18 0.13/0.18 5.8 max.grade ability, laden/unladen % 8/12 6/10 4/10 5.1 service brake electromagnetic motor 6.1 drive motor power kW 1.5(AC) 6.2 lift motor power kW 2.2(DC) 3(DC) 6.4 battery voltage/rated capacity V/Ah 24/210 24/285 6.5 battery weight kg 205 260 others 8.1 type of drive control AC 8.2 Sound level at the driver's sear according to DIN12053 dB(A) 70
Related SNSC forklift products
Our SNSC forklifts have different forklift series that can meet our customer's different needs.
1. Counter Balanced Diesel powered forklift truck range from 1.5 to 10ton;(FD30,FD35,FD40,FD45,FD50,FD60,FD70,FD80,FD100)
2. Battery powered electric forklift truck range from 1.5 to 3.5ton;
(FB15, FB20, FB25, FB30, FB35)
3. Counter Balanced LPG and gasoline powered dual fuel forklift trucks range from 1.5 to 3.5 ton;
(FL15, FL18, FL20, FL25, FL30, FL35)
4. warehouse equipments, like electric pallet truck, electric reach truck, electric stacker & electric trailer, scissor lift, double deep electric reach truck, racks.
If you have interests in our snsc forklift, welcome you to contact Nicole
