• Model NO.：FB45
• Load center：500mm
• Lift height：3000~5000mm
• Condition：New
• Fork Size：1070mm*150mm*50mm
• Wheelbase：2000mm
• Certificate：EPA ISO CE
• Max. Lifting Height：3000mm
• Overall Length(to Fork Face)：3030mm
• Battery：80,700V,Ah
• Transport Package：Container
• Specification：3030mm*1600mm*2330mm
• Trademark：LTMG
• Origin：China
• HS Code：8427109000
• Production Capacity：800sets,Year

Power source BatteryRated load capacitykg4500Load centremm500Lift heightmm3000Fork size (L×W×T)mm1070×150×50Fork carriage tilt(F/R)°6°/9°Overall Length(to fork face)mm3030Overall Widthmm1600Mast Lowered Heightmm2330Mast Extended Heightmm4255Overhead Guard Heightmm2255Wheelbasemm2000Overall length(with forks)mm4100Gradeability(Laden)%15Front Tire 28×12.5-15-24PRRear Tire 7.0-12-14PRBattery(Voltage/Capacity)V/Ah80/700Drive motor                    Kw2x11Lifte motor                       Kw26



After sales service

LTMG always treat after-sale service as important as the product quality.
LTMG grants our clients a twelve-month-period or 2000 working hours warranty for any machine purchased from us.
LTMG can also help clients coordinate with trained service personnel to provide you detailed and extensive knowledge about your specific machine. With our technical advises, your machine service life can be significantly prolonged and sustained with high capacity.
