China Material Equipment 5 Ton Forklift Truck with Optional Engine
XIAMEN LTMG CO., LTD.- Warranty：1 Year , 2000 Working Hours
- Cab Location：Not Adjustable
- Type：Powered Pallet Truck
- Power：Diesel Engine
- Load Capacity：1T - 5T
- Fuel：Diesel
Base Info
- Model NO.：FD50
- Load center：>500mm
- Lift height：3000~5000mm
- Condition：New
- Fork Size：1070*150*55mm
- Engine：Chinese Engine,Isuzu,Mitsubishi
- Weight：6980kg
- Wheelbase：2100mm
- Tire Type：Pneumatic
- Free Lift：205mm
- Color：Could Be Designed by Buyer
- Transport Package：Container
- Specification：3245*1430*2270mm
- Trademark：LTMG
- Origin：China
- HS Code：84272090
- Production Capacity：10000 Piece,Week
Description
Model FD45 FD50 Power Type Diesel Diesel Rated Capacity kg 4500 5000 Load Centre mm 500 500 Lift Height mm 3000 3000 Fork Size L×W×T mm 1070×150×50 1070×150×50 Mast Tilt Angle F/R Deg 6°/12° 6°/12° Front Overhang (Wheel center to fork face) mm 579 579 Ground Clearance(Bottom of mast) mm 150 150 Overall Dimension Length to face of fork(Without fork) mm 3260 3260 Overall Width mm 1460 1460 Mast Lowered Height mm 2270 2270 Mast Extended Height(With backrest) mm 4165 4165 Overhead Guard Height mm 2340 2340 Turning Radius (outside) mm 2910 2310 Speed Travel (Full load) km/h 25 25 Lifting (Full load) mm/s 400 380 Max.Gradeability (No load/Full load) % 20 20 Tire Front mm 300-15-18PR 300-15-18PR Rear mm 7.00-12-12PR 7.00-12-12PR Wheelbase mm 2100 2100 Service weight kg 6680 6680 Battery Voltage/Capacity V/Ah <12/80>*2 <12/80>*2 Engine Model 6BG1-05 Manufacture ISUZU Rated output/r.p.m. kw 68.4/2500 Rated torque/r.p.m. N·m 333/1500 No.of Cylinder 6 Bore×Stroke mm 105×125 Displacement cc 6494 Fuel Tank Capacity L 105 Transmission Type Hydraulic Stage FWD/RVS 2/1
Packing&shipping:
Welcome to contact us for more information!
