• Model NO.：FD50
• Lift height：3000~5000mm
• Condition：New
• Engine：Mitsubishi,Japanese Engine
• Fork Size：1220mm*150mm*60mm
• Wheel Base：2100mm
• Weight：6900kg
• Color：Decided by Buyer
• Length to Face of Fork(Without Fork)：3183mm
• Rated Power：68.4kw,2000rpm
• Total Width：1485mm
• Tread：1180mm,1190mm
• Ground Clearance：150mm
• Transport Package：Container
• Specification：3260mm*1460mm*2340mm
• Trademark：LTMG
• Origin：China
• HS Code：84272090
• Production Capacity：2000sets,Month

Model   FD50Load capacity kg5000Load center mm600Power unit  Diesel   Operator type  Driver/seat Tire type  Pnenumatic  WheelFront/rear 2/2Max. lifting height mm3000Free lift mm140Fork sizeL*W*Tmm1220*150*60Tilt rangeMast forward/backward          deg6/12Overall length(without fork) mm3183Total width mm1485Mast height (fork lowering) mm2390Overall height fork raisedWith backrest mm4295Height to head guard mm2270Turning raduis(outside) mm2865Front face of fork to front axle mm560Min. right angle stacking aislepallet size :1100×1100 add clearence mm4670SpeedMax Travelling  full/no loadkm/h18/19Lifting          full/no loadmm/s380/430Lowering       full/no loadmm/s380/340Max.drawbar pullfull/no load  kg4500/2000Gradeability at 1.6km/hfull load %25Truck weight kg7830Weight  distributionFull  load front/rear     kg10280/1790No  load  front/rear   kg3330/4500TiresNumber front/rear2/2Model front axle300-15-18PRrear axle 7.00-12-12PRWheelbase mm2000Tread Front/rearmm1180/1190Ground clearenceAt lowest point(mast)            mm100Frame mm240BrakeService  brake power brakeParking brake  Mechanical-hand leverBatteryVoltage/capacityV/AH2-12/80Engine Model  MITSUBISHI S6SRated power kw/rpm52/2300Rated torque N-m/rpm248/1700Number of cylinders  6Displacement L4.996Fuel tank capacity L80Transmissionshift stage(front/rear-type) 2-1 power shift T/MOperating pressureHydraulic system pressure     kg/cm²200
Product Features

1.Equipped with the powerful and efficient engine Isuzu 6BG1 engine,makes the forklift high handing performance.Optional Mitsubishi S6S-T engine suitable for the Europe 3 emission standard.
2.The standard LED lamps and warning lights make it safer,more energy efficient and create better working condition.
3.Noise-isolation and vibration absorber Luxury cab with the air-conditioner,back-view camera ensure easy operation and more comfortable.(Optional)
4.Steering system with the horizontal cylinder provides with the fixable and convenient veer operation and maintainability.

Factory Overview


Our Customer

Packing&Shipping


After sales service

LTMG always treat after-sale service as important as sale. Nowadays more than 50 agents around the world can supply LTMG professional after-sale service.
All the product of LTMG supplied with 1 year or 2000 working hours (which occurs first) period quality warranty.
Detail clauses and policies please check our website and product certificate.




FAQ

1.What Certificate do you have?
LTMG workshop meet with the ISO9001:2008 Quality System.
All of our products with CE certificate.  Some of our products meets the EPA requirements.
LTMG neverrecruit Underage labor.

2.Can you customize and design as the clients' requirement?
LTMG will try its best to meet all kinds of clients' special requirements.
However, All the customizing and refit should be implemented safely and scientifically.
The colors can be painted as client's need.

3.How long is the warranty of your products?
Normally 1 year or 2000 working hours whichever occurs first.
Details to see the LTMG warranty policy for each model.

4.Can you produce the products labeled with the client's brand?
With the authorization of the brand, we can OEM for our clients.

5.What payment terms do you accept?
Normally 30% T/T in advance as deposit, blance paid before shipment.
100% L/C at sight issued by world famous bank with good faith is also available.

6.Delivery time:
Standard configuration products are always in stock.
The production period of Customizing products is from 30 days.
