• Model NO.：FDS30
• Load center：600mm
• Lift height：3600mm
• Condition：New
• Wheel Base：2460mm
• Max.Lift Height：3600mm
• Min. Ground Clearance：170mm
• Free Lifting Height：0.3m
• Gradeablity：22%
• Min. Ground Clearance (Full Load)：.17m
• Max. Lifting Height：3.6m
• Min. Turning Radius：4.3m
• Brand：Ltmg
• Transport Package：Container
• Specification：4450mm*2030mm*2700mm
• Trademark：LTMG
• Origin：China
• HS Code：8427209000
• Production Capacity：100sets,Month

Rated load capacity (loader center≤0.6m)3000kgMax. lifting height3.6mfree lifting height0.3mMax. lifting speed (full load)≥0.3m/sdriving speedforward20km/hreverse20km/hFork dipping angle up/down5°/3°Min. turning radius4250mmMax. traction force20.678KNGradeablity20%Ground clearance (Bottom of mast)160mmdimensionsLength4555mmWidth (Without the back mirror)2000mmHeightfork down2460mmfork lifting4660mmWheel base2250mmTrack base1600mmPlatform length4555mmPlatform width1200mmFork size(L×W×H)1070×125×45mmMax. base of the forks0.94mBattery(V/Ah)12/80Tire2×28×9-15-12PR(front)
2×28×9-15-12PR(rear)Service weight5300kgTransmissionTypeHydraulicStageFWD/RVS1/1EngineModelYanmar 4TNE98Rated power(kw/r.p.m.)42.1/2300Rated Torque/r.p.m(kw/r.p.m.)187-207/1700
