2.5 Ton Diesel Forklift Truck with Competitive Price Sh25fr

Jinan Sinoheng Import and Export Co., Ltd.
  • Cab Location：Not Adjustable
  • Type：Powered Pallet Truck
  • Power：Diesel Engine
  • Load Capacity：1T - 5T
  • Fuel：Diesel
  • Load center：500mm

Base Info

  • Model NO.：SH25FR
  • Lift height：3000~5000mm
  • Condition：New
  • Load Capacity (T)：2.5t
  • Power Type：Diesel
  • Free Lift：60mm
  • Transport Package：Container, FCL,LCL
  • Specification：CE
  • Trademark：sinoheng
  • Origin：Shandong, China
  • Production Capacity：300PCS,Month

Description

Product Name2.5 ton Diesel Forklift TruckModelSH25FRLoad capacity (kg)2500Load center (mm)500Power typeDieselMax. lifting speeds ( with load )  mm/s400Max. driving speeds ( with/without load )  km/h17/19Max. towing ( with/without load )  kn15/10Gradeability (with/without load )  %15/20Lifting height (mm)3000Free lift (mm)60Tilting angles ( forward-backward )  (  .)6/12Min. turning radius (mm)2450Min. right angle aisel width ( mm )2050Min. under-clearance (mm)110
DimensionOverall length (including fork)mm3605Overall width ( mm )1160Overall height (mast lowered )mm2095Overall height (mast extend )mm4080Overall height to overhead guard (mm)2095Fork overhang (mm)451Wheel base (mm)1640TreadFront tread (mm)970Rear tread (mm)970TyreFront tyre                   7,00-12Rear tyre                   6,00-9Total weight (kg)3600Fork width (mm)122Fork thickness (mm)40Backrest height (mm)1000Fork length (mm)1070

EngineEngine model490Rate power (KW)39Rotate speed at Rate power (rpm)2650Max. torque  (nm)157Rotate speed at max torque (rpm)1980Type of power shiftTor-non2.5 Ton Diesel Forklift Truck with Competitive Price Sh25fr
