• Model NO.：FG30
• Fuel：Gasoline
• Load center：500mm
• Lift height：3000mm~6000mm
• Condition：New
• Weight：4300kg
• Engine：Nissan
• Fork Positioner Function：Standard Equipped
• Color：Customized
• Mast：Duplex Mast (Triplex Mast Optional)
• Optional：Side Shifter, Sealed Cab, High Mast, etc
• Certification：CE,ISO
• Transmission：Hydraulic
• Packing &Shipping：Two Units (for 3 Ton ) Fixed Container
• Turning Radius：2440
• Wheelbase：1700mm
• Transport Package：Nude Packing, Container
• Specification：2730*1225*2115mm
• Trademark：LTMG
• Origin：China
• HS Code：8427209000
• Production Capacity：300sets,Month

Manufacturer  LTMGModel Power shift T/MFG30Manual shift T/MFG30Load capacity kg3000Load center mm500Power unit  GasolineOperator type  Driver/seatTire typeFront/rear PneumaticWheelFront/rear 2/2Max. lifting height mm3000Free lift mm150Fork sizeL*W*Tmm1070*125*45Tilt rangeMast forward/backwarddeg6/12Overall length(without fork) mm2730Total width mm1285Mast height (fork lowering) mm2075Overall height fork raisedWith backrestmm4250Height to head guard mm2140Turning radius(outside) mm2460Front face of fork to front axle mm485Min. right angle stacking aisle  without load length&clearancemm2940SpeedMax Travelling full/no loadkm/h18/19.5Lifting full/no loadmm/s450/500Lowering full/no load mm/s450/420Max.drawbar pullPower shift T/M full/no loadkg1800/1000Manual shift T/M full/no loadkg1900/1000Gradeability at 1.6km/hPower shift T/M full/no load%17/20Manual shift T/M full/no load%17/20Truck weight kg4300Weight  distributionFull load front/rearkg7260/850No load front/rearkg1840/2770TiresNumberfront/rear2/2Modelfront axle28x9-15-12PRrear axle6.50-10-10PRWheelbase mm1700TreadFront/rearmm1060/970Ground clearanceAt lowest point(mast)mm120Framemm135BrakeService  brake Hydraulic-foot pedalParking brake Mechanical-hand leverBatteryVoltage/capacityV/AH12/60EngineModel Nissan K25Rated powerPS(kw/rpm)51/2300(37.4/2300)Rated torquekg-m    max.(N.m)18/1600(177/1600)Number of cylinders 4PlacementL2.488Fuel tank capacityL60TransmissionSpeed forward/backwardPower shift T/M Manual shift T/M1-1 power shift T/M 2-2 power shift T/MOperating pressureHydraulic system pressurekg/cm²180
