• Model NO.：FG35
• Lift height：3000~5000mm
• Condition：New
• Fork Size：1070mm*125mm*50mm
• Weight：4610kg
• Engine：Nissan
• Wheelbase：1700mm
• Color：Decided by Buyer
• Max. Lifting Height：3000mm
• Rated Power：51kw,2300rpm
• Tire Type：Pneumatic
• Ground Clearance：125mm
• Turning Radius(Outside)：2460mm
• Transport Package：Nude Packing, Fixed in Container
• Specification：2720mm*1285mm*2140mm
• Trademark：LTMG
• Origin：China
• HS Code：8427209000
• Production Capacity：800sets,Year

Manufacturer  LTMG
 Model Power shift T/MFG35Manual shift T/MFG35Load capacity Kg3500Load center Mm500Power unit  GasolineOperator type  Driver/seatTire typeFront/rear PneumaticWheelFront/rear 2/2Max.Lifting height Mm4500Free lift Mm150Fork sizeL*W*TMm1070*125*50Tilt rangeMast forward/backwardDeg6/12Overall length(without fork) Mm2720Total width Mm1285Mast height (fork lowering) Mm2075Overall height fork raisedWith backrestMm4250Height to head guard Mm2140Turning radius(outside) Mm2460Front face of fork to front axle Mm485Min.Right angle stacking aisleWithout load length&clearanceMm2940SpeedMax Travelling full/no loadKm/h18/19.5Lifting full/no loadMm/s450/500Lowering full/no loadMm/s450/420Max.Drawbar pullPower shift T/M full/no loadKg1800/1000Manual shift T/M full/no loadKg1900/1000Gradeability at 1.6km/hPower shift T/M full/no load%17/20Manual shift T/M full/no load%17/20Truck weight Kg4610Weight  distributionFull load front/rearKg7260/850No load front/rearKg1840/2770TiresNumberFront/rear2/2ModelFront axle28x9-15-12PRRear axle6.50-10-10PRWheelbase Mm1700TreadFront/rearMm1060/970Ground clearanceAt lowest point(mast)Mm120FrameMm135BrakeService  brake Hydraulic-foot pedalParking brake Mechanical-hand leverBatteryVoltage/capacityV/AH12/60EngineModel Nissan K25Rated powerPS(kw/rpm)51/2300(37.4/2300)Rated torqueKg-m    max.(N.M)18/1600(177/1600)Number of cylinders 4PlacementL2.488Fuel tank capacityL70TransmissionSpeed forward/backwardPower shift T/M Manual shift T/M1-1 power shift T/M
2-2 power shift T/MOperating pressureHydraulic system pressureKg/cm²180

Product Features

1.Equipped with powerful and reliable original imported Nissan engines with excellent environmental performance;Using American IMPCO gas system which is more reliable.

2.Equipped with full set of LED lamps, which are brighter and energy saving.

3.LTMG forklift trucks are designed for the operator to be more productive And require less downtime for maintenance

4.The advanced design wiring harness uses waterproof connectors and an enclosed multiunit fuse module for improved circuit security and reliability.

5.Heavy I beam and C channel mast rails are positioned to create a wider forward view of the fork tips and the load.Large rollers roll more freely under load and side thrust rollers provide added lateral support especially in wide load applications.

6.The monitor with integrated diagnostic system provides easy service and lower maintenance costs.

7.Latest technology LPG engines have EPA tier 3 and EU stage IIIA rated engines certified to meet/exceed CARB emissions.
