• Model NO.：FD30
• Lift height：3000~5000mm
• Condition：New
• Fork Size：1070mm*125mm*45mm
• Weight：4380kg
• Engine：Isuzu
• Wheelbase：1700mm
• Prouduct Name：Mini 3 Ton Diesel Forklift with Fd30t Names
• Max. Lifting Height ：3000mm
• Rated Power：34.3kw,2500rpm
• Tire Type ：Pnumatic
• Turning Radius(Outside)：2445mm
• Truck Weight：4380kg
• Transport Package：Container
• Specification：2705mm*1225mm*2140mm
• Trademark：LTMG
• Origin：China
• HS Code：84272090
• Production Capacity：1000sets,Year

Manufacturer    LTMGModel  Power shift T/MFD30  Load capacity   kg3000Load center   mm500Power unit    Diesel   Operator type    Driver/seat  Tire type    Pneumatic Wheel  Front/rear  2/2Max. lifting height mm3000Free lift mm150Fork size  L*W*Tmm1070*125*45Tilt range Mast forward/backward deg6/12Overall length(without fork) mm2705Total width mm1225Mast height (fork lowering) mm2075Overall height fork raisedWith backrest mm4250Height to head guard mm2140Turning radius(outside)  mm2445Front face of fork to front axle mm480Min. right angle stacking aislewithout load length&clearancemm2925SpeedMax Travelling full/no loadkm/h18/19.5Lifting full/no loadmm/s450/500Lowering full/no loadmm/s450/450Max.drawbar pullPower shift T/M full/no loadkg1500/1000Manual shift T/M full/no loadkg1550/1000Gradeability at 1.6km/hPower shift T/M full/no load%18/20Manual shift T/M full/no load%18/20Truck weight kg4380Weight distributionFull load front/rearkg6490/890No load front/rearkg1670/2700TiresNumber front/rear 2/2Model front axle  28x9-15-12PRrear axle 6.50-10-10PRWheelbase mm1700TreadFront/rear mm1000/970Ground clearanceAt lowest point(mast)mm120Frame mm135BrakeService brake  Hydraulic-foot pedal  Parking brake  Mechanical-hand lever BatteryVoltage/capacity V/AH12/80EngineModel  ISUZU C240Rated power kw/rpm34.3/2500Rated torque N.m/rpm138/1800Number of cylinders  4Placement L2.369Fuel tank capacityL70Transmission Speed forward/backward        Power shift T/M
Manual shift T/M 1-1 power shift T/M
2-2 manual shift T/M
