• Model NO.：FRB16
• Fuel：Electric
• Load center：600mm
• Lift height：8m
• Condition：New
• Max.Lifting Height：8m
• Brand：Ltmg
• Rated Capacity：1600kg or 2000kg
• Type of Drive Motor：AC
• Color：Customized
• Power Type：Battery
• Operation Type：Seated
• Wheelbase：1426mm
• Battery Voltage/Capacity：48,420V,Ah
• Transport Package：Fixed in Container or Nude Packing
• Specification：1825*1270*2075mm
• Trademark：LTMG
• Origin：China
• HS Code：8427109000
• Production Capacity：10000sets,Year

Standard1.1Brand LTMGLTMG1.2Model FRB16FRB201.3Power Type BatteryBattery1.4Operation Type SeatedSeated1.5Rated CapacityQ(kg)160020001.6Load CenterC(mm)600600Tire, Rim2.1Tyres,front/rear Solid PU Solid PU2.2Tyre size,frontmm φ280×135φ300×1202.3Tyre size,drive wheelmm φ343×108φ343×1202.4Tyre size,balance wheelmm //2.5Tyres No. front/rear (X=drive) 2 / 1X 2 / 1X Dimension3.1Tilt of fork forward/backwardα/β(°)3/53/53.2Lift heighth1(mm)300030003.3Free lift heighth2(mm)//3.4Height-Mast  Loweredh3(mm)207521753.5Height-Mast extended w/ backrest h4(mm)464247423.6Height-Overhead guardh5(mm)220622363.7Height of legsh6(mm)2382753.8Height of first pedalh7(mm)3463763.9Height of second pedalh8(mm)6136433.10Height of Seath9(mm)103310633.11Height-From second pedal to overhead guardh10(mm)151315133.12Ground clearance of legm1(mm)701003.13Ground clearance of bottomm2(mm)50803.14Min. ground clearance of mastm3(mm)75753.15Overall Length (incl. fork)L1(mm)234024273.16Overall Length (without fork)L2(mm)182519443.17Reach StrokeL3(mm)6106173.18Front Overhangx(mm)2152103.19Wheelbasey(mm)142615253.20Overall Widthb1/b2(mm)12701270/12903.21Tread front/rearb3/b4(mm)1134/01170/03.22Inner distance between legsb5(mm)8948903.23Distance between fork-armsb6(mm)200-680200-6803.24Fork DimensionsL/e/s(mm)1070×100×351070×100×353.25Aisle width for pallet 1200*800 crosswaysAst1(mm)274328533.26Aisle with for pallet 1000*1200 crosswaysAst2(mm)269628103.27Turning radiusWa(mm)16651765Function4.1Travel Speed ,laden/unladenkm/h8.5/108.5/104.2Lift Speed ,laden/unladenmm/s200/200185/1854.3Lowering speed,laden/unladenmm/s270/200270/2004.4Max. Gradeability,laden/unladen%≤10≤10Power5.1Type of Drive Motor ACAC5.2Drive Motorkw5.55.55.3Type of Lift motor ACAC5.4Lift motorkw8.68.65.5Battery voltage/capacityV/Ah48/42048/560Weight6.1Battery weightkg7609206.2Service weight(incl. battery)kg30183258Steering,Braking7.1Steering type hydraulic hydraulic7.2 Parking Brake type Drum BrakeDrum Brake7.3Parking Operation type Pedal Brake Pedal Brake7.4Service Brake type Hand BrakeHand BrakeOther8.1Battery Change type Front Pull ChangingFront Pull Changing
Curtis ControllerRamp Auxiliary Braking System Full AC SystemForward Speed-limited at high liftDrum BrakeHigh Capacity BatterySolid PU WheelIntelligent Charger
Options:LED Warning LampMulti-functional meterCameraSide Shift etc attachmentsSpecial Used For Drive-in RackCold Storage UseExplosion-proof UseImported Battery

Packaging&Shipping

Customer:
