Ce Mark All Rough Terrian Forklift Truck
Wuhan Fusen Machinery Co., Ltd.- Cab Location：Adjustable
- Type：Diesel Forklift
- Power：Diesel Engine
- Load Capacity：1T - 5T
- Fuel：Diesel
- Load center：500mm
Base Info
- Model NO.：CPCY50
- Lift height：3000~5000mm
- Condition：New
- Engine：Xinchai 490
- Lifting Height：3m to 6m
- Standard Mast：2-Stage
- Fork Length：1220mm
- Transport Package：Nude
- Specification：5.0 ton
- Origin：China
- HS Code：84272090
- Production Capacity：500PCS,Month
Description
Basic Info.
Model NO. CPCY50 Lift height 3000~5000mm Condition New Engine Xinchai 490 Lifting Height 3m to 6m Standard Mast 2-Stage Fork Length 1220mm Transport Package Nude Specification 5.0 ton Origin China HS Code 84272090 Production Capacity 500PCS/MonthProduct Description
5T Rough terrain 4WD forklift with CE and EPA
Product Description
FAW brand 4DX21-72 model 57 kw diesel engine.Dongfeng CUMMINS 4BTA3.9-C100 in optional.
Automatic transmission.
1.52 meter fork length.
Cabin with air heater.
Duplex mast 3 meter lifting height.
Rated load 5 tons.
Dead weight: 8000kgs
40 feet container 2 units.
| Model | CPCY 50 |
| Rated load (kg) | 5000 |
| Lifting height (mm) | 3000 |
| Load centre | 600 |
| Without Pallet fork Length (mm) | 4420 |
| Width (mm) | 2185 |
| Max. height To the cab top (mm) | 3100 |
| Mast Tilt Angle(Front/Rear) | 6/12 |
| Wheelbase (mm) | 2185 |
| Tread | 1575 |
| Tyres | 16/70-20 (14PR) |
| Self weight | 7900 |
| Battery Voltage/Capacity | 24 V ( 80ahx2 ) |
| Standard Engine brand | FAW |
| Standard engine model | 4DX21-72 |
| Standard engine power (kw) | 57 |
| Transmission | Automatic 2F/2R |
| Unload Max speed (km/H) | 25 |
| Max. Gradeability (Laden) % | 22 |
| Fork size L×W×T (mm) | 1520*150*55 |
| Min. ground clearance(drive steer axle)(mm) | 285 |
| Turning radius (mm) | 5290 |
