3ton All Terrian Rough Forklift Truck with Ce Mark
Wuhan Fusen Machinery Co., Ltd.- Cab Location：Adjustable
- Type：Diesel Forklift
- Power：Diesel Engine
- Load Capacity：1T - 5T
- Fuel：Diesel
- Load center：500mm
Base Info
- Model NO.：CPCY30
- Lift height：3000~5000mm
- Condition：New
- Engine：Xinchai 490
- Lifting Height：3m to 6m
- Standard Mast：2-Stage
- Fork Length：1220mm
- Transport Package：Nude
- Specification：3.0 ton
- Origin：China
- HS Code：84272090
- Production Capacity：500PCS,Month
Description
Basic Info.
Model NO. CPCY30 Lift height 3000~5000mm Condition New Engine Xinchai 490 Lifting Height 3m to 6m Standard Mast 2-Stage Fork Length 1220mm Transport Package Nude Specification 3.0 ton Origin China HS Code 84272090 Production Capacity 500PCS/MonthProduct Description
3T Rough terrain 4WD forklift with CE and EPA
Product Description
Xinchai 490 model 40 kw diesel engine Two ways valves, Automatic transmission.
1.22 meter pallet fork length.
Cabin with air heater.
Duplex mast 3 meter lifting height.
Rated load 3 tons.
Dead weight: 4340kgs
| Model | CPCY 30 |
| Rated load (kg) | 3000 |
| Lifting height (mm) | 3000 |
| Load centre | 500 |
| Without Pallet fork Length (mm) | 3515 |
| Width (mm) | 1700 |
| Max. height To the cab top (mm) | 2720 |
| Mast Tilt Angle(Front/Rear) | 6/12 |
| Wheelbase (mm) | 2080 |
| Tread | 1170 |
| Tyres | 12-16.5 (14PR) |
| Self weight | 4340 |
| Battery Voltage/Capacity | 24 V ( 80ahx2 ) |
| Standard Engine brand | XINCHAI |
| Standard engine model | C490 BPG |
| Standard engine power (kw) | 40 |
| Transmission | Automatic 2F/2R |
| Unload Max speed (km/H) | 28 |
| Max. Gradeability (Laden) % | 22 |
| Fork size L×W×T (mm) | 1220*125*45 |
| Min. ground clearance(drive steer axle)(mm) | 260 |
| Turning radius (mm) | 4500 |
