• Model NO.：FD20
• Load center：500mm
• Lift height：3000mm
• Condition：New
• Optional：Cab with AC, Fork Positioner, Solid Tyre etc
• Fork Size：1070mm*120mm*40mm
• Weight：3590
• Engine：Isuzu ( or Chinese Engine Optional)
• Wheelbase：1600mm
• Color：Customize
• Tire：Pneumatic
• Gound Clearance：110mm
• Operator Type：Driver,Seat
• Transport Package：Container
• Specification：2595mm*1150mm*2070mm
• Trademark：LTMG
• Origin：China
• HS Code：84272090
• Production Capacity：800sets,Year

Manufacturer  LTMGModel Power shift T/M FD20Manual shift T/MFD20Load capacity   kg2000Load center mm500Power unit   Diesel Operator type   Driver/seatTire type   PneumaticWheel  Front/rear 2/2Max. lifting height mm3000Free lift  mm160Fork size L*W*Tmm1070*122*40Tilt rangeMast forward/backwarddeg6/12Overall length(without fork)  mm2460Total width mm1150Mast height (fork lowering)   mm1995Overall height fork raised With backrest mm4030Height to head guard             mm2120Turning radius(outside)   mm2170Front face of fork to front axle  mm450Min. right angle stacking aislewithout load length&clearancemm2615Speed Max Travelling full/no loadkm/h17/19Lifting  full/no loadmm/s550/580Lowering  full/no loadmm/s450/550Max.drawbar pull Power shift T/M full/no loadkg1670/830Manual shift T/M full/no loadkg1700/830Gradeability at 1.6km/hPower shift T/M full/no load%27/20Manual shift T/M full/no load  %21/20Truck weight kg3330Weight  distributionFull  load  front/rearkg4700/630No  load                            front/rear                                 kg1510/1820Tires Numberfront/rear2/2Modelfront axle 7.00-12-12PRrear axle6.00-9-10PRWheelbase mm1600Tread Front/rearmm970/970Ground clearanceAt lowest point(mast)mm110Framemm115BrakeService  brake Hydraulic-foot pedal  Parking brake Mechanical-hand leverBatteryVoltage/capacityV/AH12/80EngineModel Mitsubishi S4SRated powerkw/rpm35.4/2250Rated torqueN.m/rpm170/1700Number of cylinders 4PlacementL2.369Fuel tank capacityL70TransmissionSpeed forward/backwardPower shift T/M Manual shift T/M 1-1 power shift T/M
2-2 manual shift T/MOperating pressureHydraulic system pressurekg/cm²180Product Features

1.Safe:
LED work lights and warning lights make it safer and more efficient evenin poor lighting conditions.
New designed overhead guard protective device prevent the sudden accidents.
Thicker reinforcing plate ensure the safety and efficiency.

2.Easy to operate:
Linde-Technology single chain with reinforced load backrest--makes an excellent and wider field of visionfor operator.

3.Beautiful and comfortable:
New suspension adjustable seat makes the long time operating more comfortable.
Step area is 1.5 times larger with lower step height than fellow forklifts.

4.Durable:
Sunken tilt cylinder under the floor build broader flat floor and less abrasion.
Change plastic slider to alloy copper slider, reduce the abrasion and narrow the gap between masts.
Thicker steering axle bridge deck.

5.Environmental:
Middle muffler, more environmental.

6.High technology:
Maintenance free radiators adopt Germany technology.

Certificates



Packing&Shipping



Factory & Customers show:




After sales service

LTMG always treat after-sale service more important than sale.
Nowadays more than 100 agents around the world can supply LTMG professional after-sale
service.
All the product of LTMG supplied with one year or 2000 working hours (which occurs first)
period quality warranty.
Detail clauses and policies please check our website and product certificate.



Contact Me



FAQ

1.What Certificate do you have?
LTMG workshop meet with the ISO9001:2008 Quality System.
All of our products with CE certificate.  Some of our products meets the EPA requirements.
LTMG neverrecruit Underage labor.

2. Can you customize and design as the clients' requirement?
LTMG will try its best to meet all kinds of clients' special requirements.
However, All the customizing and refit should be implemented safely and scientifically.
The colors can be painted as client's need.

3.How long is the warranty of your products?
Normally 1 year or 2000 working hours whichever occurs first. Details to see the LTMG warranty policy for each model.

4. Can you produce the products labeled with the client's brand?
With the authorization of the brand, we can OEM for our clients.

5. What payment terms do you accept?
Normally 30% T/T in advance as deposit, blance paid before shipment.
100% L/C at sight issued by world famous bank with good faith is also available.

6.Delivery time:
Standard configuration products are always in stock.
The production period of Customizing products is 30 days.
