eristics

model

TB20-RA1

TB25-RA1

drive

electric

electric

operator type

load  capacity

Q(kg)

2000

2500

load centre

c(mm)

600

600

front overhang

x(mm)

815/865/935

815/865/935

wheel base

Y(mm)

1211/1261/1331

1211/1261/1331

weight

capacity(with battery)

kg

710

740

axle loading ,laden(front/rear)

kg

1300/1410

1470/1770

axle loading ,unladen(front/rear)

kg

600/110

620/120

wheels chassis

tyres type

polyurethane

polyurethane

wheel size (front)

250×70

250×70

wheel size (rear)

82×126

82×126

additional wheels

127×57

127×57

wheels ,number front/rear (x = drven wheels)

1X-2/2

1X+2/2

track width (front)

b10(mm)

490

490

track width (rear)

b11(mm)

340/370/470/505

340/370/470/505

/

lifting height

h3(mm)

120

120

height of tiller in driving position min/max

h14(mm)

1150/1430

1150/1430

height ,fork lowered

h13(mm)

82

82

length

l1(mm)

1710/1760/1830

1710/1760/1830

length to face of forks

l2(mm)

610

610

width

b1(mm)

775

775

fork dimentions

s/e/l(mm)

54×180×1100 (1150/1220)

54×180×1100(1150/1220)

width across forks

b5(mm)

520/550/650/685

520/550/650/685

ground clearance centre of wheelbase

m2(mm)

28

28

aisel width,pallet 1000x1200(1200crossways)

Ast(mm)

1910/1960/2030

1910/1960/2030

aisel width,pallet 800x1200(1200lengthways)

Ast(mm)

2010/2010/2030

2010/2010/2030

turning radius

Wa(mm)

1550/1600/1670

1550/1600/1670

Dimensions

travel speed ,laden/unladen

Km/h

6.7/7.1

6.7/7.1

lifting  speed laden/unladen

m/s

0.039/0.056

0.039/0.056

lowering speed , laden/unladen

m/s

0.064/0.050

0.064/0.050

max.grade ability, laden/unladen

%

8/20

8/20

service brake

electromagnetic

electromagnetic

motor

drive motor power

kW

1.2

1.5

lift motor power

kW

1.2

1.2

battery voltage/rated capacity

V/Ah

24/210

24/240

battery weight

Kg

170

200

others

type of dirve control

AC

AC

soundlevel at the driver's sear according to DIN12053

dB(A)

70

70

OUR SERVICE
1)Professional fast response mechanical engineers and electrical engineers provide suitable solution method for you all around the world.
2)Engineers available to reach machinery overseas job site at any time required.
3) Technical Support of installation/training supplied to help customers to earn most profits with our machinery.
4) All variety of spare parts available to support the customer 24h*7days for the daily maintenance/repair purpose etc.
OUR PRICE
We work as the leading VIP dealers of various famous Chinese construction machinery manufacturers and are constantly treated with best price policy which is only provided to special internal high level permission.From numerous comparison and feedback from clients.Our price is always more competitive and much favorable than the customer buy directly from manufacturers.
OUR PRODUCTS
Established in 2010, Anhui heavy and light industries International Group, which is located in Hefei City, the provincial capital of Anhui Province, China, has business for construction machinery,international trade, finance investment and education.
As the leading construction machinery exporter in China. We has over 100 countries international business and the annual sales figure exceeds USD 100 million.
It is an important export partner of the world famous brands such as SINOTRUK,SHACMAN,North BEIBEN,DONGFENG,FOTON,,ZOOMLION,HELI,CAMC,SDLG,SEM,LONGKING,LIUGONG,HANGCHA,HYUNDAI,DOOSAN,YTO,CIMC,etc. And manages the export of spare parts for these products with a stable customers network and good reputation worldwide.
