• Model NO.：dB12,15-Wa1
• Lift height：3000~5000mm
• Condition：New
• MOQ：1 Piece
• Transport Package：Nude Packing
• Trademark：H&L
• Origin：China
• HS Code：8429521200
• Production Capacity：50000,Year

Overview Product DescriptionCharacteristics1.1model DB12-WA1 DB15-WA1  DB15-WA1      (standard ) 1.2drive batterybatterybattery1.3operator type walkiewalkiewalkie1.4load  capacity Q(kg)1200150015001.5load centrec(mm)5006006011.6front overhangx(mm)6976986991.7wheel base Y(mm)133514101383weight2.1capacity(with battery)kg660/710/740/760780/830/840/85012202.2axle loading ,unladen(front/rear)kg1060/8701280/10701440/12802.3axle loading ,laden(front/rear)kg560/170650/200870/350wheels chassis3.1tyres type polyurethanepolyurethanepolyurethane3.2wheel size (front) φ250×70φ250×71φ250×723.3wheel size (rear) φ80×70φ80×71φ80×843.4additional wheels φ150×60φ150×61φ150×623.5wheels ,number front/rear (x = drven wheels) 1x+1/41x+1/51x+1/63.6track width (front)b10(mm)5205215223.7track width (rear)b11(mm)410/525410/526410/527dimentions 4.1ciosed mast heighth1(mm)2087/1837/2087/223752087/1837/2087/223762050/2210/24104.2lifting heighth3(mm)1600/2500/3000/33001600/2500/3000/33014500/5000/56004.3height ,mast extendedh4(mm)22087/3087/3587/388722087/3087/3587/38885070/5560/61504.4height of tiller in driving position min/maxh14(mm)670/1300670/1301670/13024.5height ,fork loweredh13(mm)9091924.6lengthl1(mm)1965204519504.7length to face of forksl2(mm)7928788784.8widthb1(mm)8208218224.9fork dimentions s/e/l(mm)60/170/1070(1150)60/170/1070(1151)60/180/1070(1150)4.10width across forksb5(mm)580/695580/696570/6954.11ground clearance centre of wheelbasem2(mm)2829314.12aisel width,pallet 1000x1200(1200crossways)Ast(mm)2400248024504.13aisel width,pallet 800x1200(1200lengthways)Ast(mm)2370245024204.14turning radius Wa(mm)152516051575Dimensions5.1travel speed ,laden/unladenKm/h5.3/5.65.8/65.8/65.2lifting  speed laden/unladenm/s0.06/0.130.06/0.140.11/0.155.3lowering speed , laden/unladenm/s0.13/0.100.13/0.110.12/0.125.8max.grade ability, laden/unladen%6/156/168/155.1service brake electromagneticelectromagneticelectromagneticmotor6.1drive motor power kW0.81.22.26.2lift motor powerkW2.23.236.4battery voltage/rated capacityV/Ah24/12024/20024/240(300)6.5battery weightkg90160220(260)others8.1type of dirve control  DCACAC8.2soundlevel at the driver's sear according to DIN12053dB(A)707172Company Profile

Our Advantages

OUR SERVICE
1)Professional fast response mechanical engineers and electrical engineers provide suitable solution method for you all around the world.
2)Engineers available to reach machinery overseas job site at any time required.
3) Technical Support of installation/training supplied to help customers to earn most profits with our machinery.
4) All variety of spare parts available to support the customer 24h*7days for the daily maintenance/repair purpose etc.
OUR PRICE
We work as the leading VIP dealers of various famous Chinese construction machinery manufacturers and are constantly treated with best price policy which is only provided to special internal high level permission.From numerous comparison and feedback from clients.Our price is always more competitive and much favorable than the customer buy directly from manufacturers.
OUR PRODUCTS
Established in 2010, Anhui heavy and light industries International Group, which is located in Hefei City, the provincial capital of Anhui Province, China, has business for construction machinery,international trade, finance investment and education.
As the leading construction machinery exporter in China. We has over 100 countries international business and the annual sales figure exceeds USD 100 million.
It is an important export partner of the world famous brands such as SINOTRUK,SHACMAN,North BEIBEN,DONGFENG,FOTON,,ZOOMLION,HELI,CAMC,SDLG,SEM,LONGKING,LIUGONG,HANGCHA,HYUNDAI,DOOSAN,YTO,CIMC,etc. And manages the export of spare parts for these products with a stable customers network and good reputation worldwide.


FAQ
1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted
2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC,
3: What about the delivery time?
A: 7-20 days after receiving the deposit.
4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.
5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs
