• Model NO.：SRSC1009-6E
• Lift height：>5000mm
• Condition：New
• Rated Power：164,2300kw,Rpm
• Max.Torque：949,1400nm,Rpm
• Emission Standard：Tier III
• Max.Lifting Height：16200mm
• Overall Weight：39t
• Max.Load：10t
• Min.Ground Clearance：250mm
• Min.Turning Radius：6800mm
• Transport Package：Nude Package
• Specification：11000mm*6053-12185mm*4000mm
• Trademark：san*y
• Origin：Hunan, China
• HS Code：8427900000
• Production Capacity：1000units,Year

ConfigurationEngineCUMMINS QSB6.7Rated power164/2300kW/rpmMax.torque949/1400Nm/rpmEmission standardTier IIITransmissionCLARK 13.7HR32334Drive axleKessler D81 PL488Tire14.00-24 28PRSpreaderModelSDJE100Side shift range±800mmRotation angle+105°/-195°Self weight4.7tApplicationISO 20'/40'/45'BoomMax.lifting height16200mmBoom tilt angle0°-64.5°PerformanceMax.lifting speed (non-load/load)450/400mm/sMax.lowering speed (non-load/load)400/400mm/sMax.travel speed (non-load/load)28/25km/hGradeability (non-load/load)33/27%Hydraulic system work pressure220barOverall weight39tMax.load10tStacking height6(8'6")Overall length11000mmWheel base5000mmOverall height4000mmMin.ground clearance250mmOverall width6053-12185mmFront wheel width3280mmRear wheel width2450mmMin.turning radius6800mm20"container aisle width10000mm40"container aisle width13600mm
