• Model NO.：FD45
• Lift height：3000~5000mm
• Condition：New
• Name：Diesel Forklift
• Brand：Zoomlion
• Load Center(mm)：500
• Power Type：Diesel
• Maximum Lifting Height：3000mm
• Free Lifting Height：146mm
• Min.Turning Radius：2760mm
• Min.Ground Clearance：160mm
• Overhead Guard Height：2350mm
• Height From Seat to Overhead Guard：1040mm
• Front Overhang：558mm
• Mast Extended Height：4257mm
• Mast Lowered Height：2355mm
• Transport Package：Nude
• Specification：4500kg
• Trademark：ZOOMLION
• Origin：China
• HS Code：8427209000
• Production Capacity：1000pes,Year

SpecificationsUnitFD40(mechanical )FD45(mechanical )CharacteristicsPower dieseldieselRated Capacitykg40004500Center of loadmm500500Lifting heightmm30003000Free lifting heightmm146146Forks L×W×Hmm1070×150×501070×150×50Tilt Forward/Backward.6/126/12Min.turning radiusmm27602760Min.ground clearance(Mast)mm160160Overhead guard heightmm23502350Height from seat to overhead guardmm10401040Front overhangmm558558PerfMax.traveling speed(loaded)km/h1818Max.lifting speed(loaded/empty)mm/s380/400380/400Drawbar pull/GradeabilitykN/%22/2022/20DimensionsOverall length (without fork)mm30603060Overall widthmm14901490Mast lowered height mm23552355Mast extended heightmm42574257ChassisTireFront 8.25-15-14PR8.25-15-14PRRear 7.00-12-12PR7.00-12-12PRWheelbasemm20002000Tread widthFront/Rearmm1180/11901180/1190Curb weightNone-loadkg60906320PowertrainBatteryVoltage/CapacityV/Ah(12/90)×2(12/90)×2EngineModel XC 4D35GXC 4D35GRated powerkw/r.p.m48/230048/2300Rated torqueNm/r.p.m230/1600-1800230/1600-1800Cylinder amount 44Bore×Stroke mm98x11598x115DisplacementL3.473.47Fuel tankL100100Transmission 2/2 mechanical transmissionWorking pressureMPa18.518.5
