2500kg Loading Capacity Manual Hydraulic Hand Pallet Truck with PU Wheel
Shenzhen Sunlight Hardware Co., Ltd.- Cab Location：Not Adjustable
- Type：Manual Pallet Truck
- Load Capacity：1T - 5T
- Load center：500mm
- Condition：New
- Wheel Material：PU,Nylon , Rubber Wheel
Base Info
- Model NO.：HPT-001
- Forklift Width：550,685mm
- Forklift Length：1150,1220mm
- Color：Yellow or Customized
- High Fork Height L：115mm
- Low Fork Height H：75mm
- Bracket Inner Width D：230 ,365mm
- Bracket Single Fork：160mm
- Front Wheel Diameter：74*70
- Rear Wheel Diameter：180*50
- Transport Package：Non-Fumigation Pallet
- Specification：customized size
- Origin：China
- HS Code：8427900000
- Production Capacity：500000PC,Year
Description
Hand Pallet TruckPU/Nylon 685x1220x75/85mm 3000kgs PU/Nylon 550x1150x75/85mm 3000kgs PU/Nylon 685x1220x75/85mm 2500kgs PU/Nylon 550x1150x75/85mm 2500kgs PU/Nylon 685x1220x75/85mm 2000kgs PU/Nylon 550x1150x75/85mm 2000kgs
3000kg loading capacity hand pallet truck:
FAQ:
Q1:what's the lead time?
within15-25days days
Q2:where is your factory located?
Our factory is located in Jiangning District of Nanjing,which is near to Nanjing port or Shanghai Port.
Q3:what's your warranty time?
5 years warranty and lifetime insurance service of all racking products. any qualtity issues that caused by quality of products , we will provide free parts for replacement.
Q4:Are you able to provide installation service?
sorry , we dont supply installation service, but we could come up with a detail instruction & essembling layout, which will help your working team to install.
Q5: What's your material grade ?
Mild Steel Q235
Q6: How is the packing?
Plastic banding + Stretch film wrapped, palletized for easy loading and unloading with Standard forklift truck or pallet jack
Q7: What's payment terms ?
TT or L/C at sight
Q8: What surface finishing of your products?
In general, we have light duty(100~300kg) model, medium duty(400~800kg) model
And heavy duty(1000~1700kg) model available for your choice.
Q10: Is custom size available?
Yes, we do custom products and projects.
| SPECIFICATION | MODEL | MODEL | |
| Load Capacity | kg | 2000 | 2000 |
| Lift height H | mm | 190 | 200 |
| Low Fork Height H | mm | 75 | 85 |
| High Fork Height L | mm | 115 | 115 |
| Fork W*L | mm | 550*1150 685*1220 | 550*1150 685*1220 |
| Bracket Inner Width D | mm | 230 365 | 230 365 |
| Bracket Single Fork | mm | 160 | 160 |
| Front Wheel Diameter | mm | 74*70 | 80*70 |
| Rear Wheel Diameter | mm | 180*50 | 180*50 |
| Wheel Material | PU/NYLON | PU/NYLON | |
3000kg loading capacity hand pallet truck:
| SPECIFICATION | MODEL | MODEL | ||
| Load Capacity | kg | 2500 | 3000 | |
| Lift height H | mm | 190/200 | 190/200 | |
| Low Fork Height H | mm | 75/85 | 75/85 | |
| High Fork Height L | mm | 115 | 115 | |
| Fork W*L | mm | 550*1150 685*1220 | 550*1150 685*1220 | |
| Bracket Inner Width D | mm | 230 365 | 230 365 | |
| Bracket Single Fork | mm | 160 | 160 | |
| Front Wheel Diameter | mm | 74*70/80*70 | 74*70/80*70 |
FAQ:
Q1:what's the lead time?
within15-25days days
Q2:where is your factory located?
Our factory is located in Jiangning District of Nanjing,which is near to Nanjing port or Shanghai Port.
Q3:what's your warranty time?
5 years warranty and lifetime insurance service of all racking products. any qualtity issues that caused by quality of products , we will provide free parts for replacement.
Q4:Are you able to provide installation service?
sorry , we dont supply installation service, but we could come up with a detail instruction & essembling layout, which will help your working team to install.
Q5: What's your material grade ?
Mild Steel Q235
Q6: How is the packing?
Plastic banding + Stretch film wrapped, palletized for easy loading and unloading with Standard forklift truck or pallet jack
Q7: What's payment terms ?
TT or L/C at sight
Q8: What surface finishing of your products?
- Electrol galvanized/Zinc plated: The zinc serves as a sacrificial anode( indoor storage)
B. Hot DIP galvanized: It forms a coating of corrosion-resistant zinc(indoor/outdoor and cold storage)
C. Powder coating: A type of coating that is applied as a free-flowing, Dry powder(indoor/outdoor storage)
In general, we have light duty(100~300kg) model, medium duty(400~800kg) model
And heavy duty(1000~1700kg) model available for your choice.
Q10: Is custom size available?
Yes, we do custom products and projects.
