3 Ton Rubber Wheel Hydraulic Hand Pallet Truck Pallet Jacks with CE Test

Shenzhen Sunlight Hardware Co., Ltd.
  • After-sales Service:Yes
  • Warranty:Yes
  • Cab Location:Not Adjustable
  • Type:Manual Pallet Truck
  • Load Capacity:1T - 5T
  • Load center:500mm

Base Info

  • Model NO.:HPT-004
  • Condition:New
  • Wheel Material:PU,Nylon , Rubber Wheel
  • Forklift Width:550,685mm
  • Forklift Length:1150,1220mm
  • Color:Yellow or Customized
  • High Fork Height L:115mm
  • Low Fork Height H:75mm
  • Bracket Inner Width D:230 ,365mm
  • Bracket Single Fork:160mm
  • Front Wheel Diameter:74*70
  • Rear Wheel Diameter:180*50
  • Transport Package:Non-Fumigation Pallet
  • Specification:customized size
  • Origin:China
  • HS Code:8427900000
  • Production Capacity:500000PC,Year

Description

Hand Pallet TruckPU/Nylon685x1220x75/85mm3000kgsPU/Nylon550x1150x75/85mm3000kgsPU/Nylon685x1220x75/85mm2500kgsPU/Nylon550x1150x75/85mm2500kgsPU/Nylon685x1220x75/85mm2000kgsPU/Nylon550x1150x75/85mm2000kgsParameter:2000kg loading capacity hand pallet truck:
SPECIFICATION MODELMODEL
Load Capacitykg20002000
Lift height Hmm190200
Low Fork Height Hmm7585
High Fork Height Lmm115115
Fork W*Lmm550*1150 685*1220550*1150  685*1220
Bracket Inner Width Dmm230 365230 365
Bracket Single Forkmm160160
Front Wheel Diametermm74*7080*70
Rear Wheel Diametermm180*50180*50
Wheel Material PU/NYLONPU/NYLON


3000kg loading capacity hand pallet truck:
SPECIFICATION MODELMODEL
Load Capacitykg25003000
Lift height Hmm190/200190/200
Low Fork Height Hmm75/8575/85
High Fork Height Lmm115115
Fork W*Lmm550*1150  685*1220550*1150  685*1220
Bracket Inner Width Dmm230 365230 365
Bracket Single Forkmm160160
Front Wheel Diametermm74*70/80*7074*70/80*70
3 Ton Rubber Wheel Hydraulic Hand Pallet Truck Pallet Jacks with CE Test3 Ton Rubber Wheel Hydraulic Hand Pallet Truck Pallet Jacks with CE Test3 Ton Rubber Wheel Hydraulic Hand Pallet Truck Pallet Jacks with CE Test3 Ton Rubber Wheel Hydraulic Hand Pallet Truck Pallet Jacks with CE Test3 Ton Rubber Wheel Hydraulic Hand Pallet Truck Pallet Jacks with CE Test
FAQ:
Q1:what's the lead time?
within15-25days days

Q2:where is your factory located?
Our factory is located in Jiangning District of Nanjing,which is near to Nanjing port or Shanghai Port.

Q3:what's your warranty time?
5 years warranty and lifetime insurance service of all racking products. any qualtity issues that caused by quality of products , we will provide free parts for replacement.

Q4:Are you able to provide installation service?
sorry , we dont supply installation service, but we could come up with a detail instruction & essembling layout, which will help your working team to install.

Q5: What's your material grade ?
Mild Steel Q235

Q6: How is the packing?
Plastic banding + Stretch film wrapped, palletized for easy loading and unloading with Standard forklift truck or pallet jack
Q7: What's payment terms ?
TT or L/C at sight
Q8: What surface finishing of your products?
  1. Electrol galvanized/Zinc plated: The zinc serves as a sacrificial anode( indoor storage)
    B. Hot DIP galvanized: It forms a coating of corrosion-resistant zinc(indoor/outdoor and cold storage)
    C. Powder coating: A type of coating that is applied as a free-flowing, Dry powder(indoor/outdoor storage)
Q9:What's the loading capacity?
In general, we have light duty(100~300kg) model, medium duty(400~800kg) model
And heavy duty(1000~1700kg) model available for your choice.
Q10: Is custom size available?
Yes, we do custom products and projects.
