• Model NO.：LG70DT
• Lift height：3000~5000mm
• Condition：New
• Warranty：1 Year
• Fork Length：1220mm
• Transport Package：Nude Packing
• Specification：5486*2230*2850mm
• Trademark：LONKING
• Origin：China
• HS Code：842720900
• Production Capacity：5000

MODEL

LG70DT

Power type

Diesel

Rated capacity(Kg)

7000

J Load centre(mm)

600

h1STDMaxliftingheight(mm)

3000

h3Freeliftingheight(mm)

200

L5*W*TSTD Fork size(mm)

1220×150×65

Mast tilt angle(deg)

6/12

L3Frontoverhang(mm)

600

L4Rearoverhang(mm)

720

R1Min.turningradius(mm)

3370

Min. width for pallets 1,000×1,200 crossways (L×W)(mm)

5170

Speed(load/unload)

Max. traveling speed(km/h)

29

Max, lifting speed(mm/s)(load/unload)

500/530

Max. gradient(%)

32

STD Dead weight(kg)

9600

S/P Tread(front/rear)(mm)

1470/1700

L2Axledistance(mm)

2300

Fm2 Mast(mm)

200

m1 Frame(mm)

230
