• Model NO.：FG35
• Lift height：3000mm
• Condition：New
• Fork Size：1070mm*125mm*50mm
• Weight：4610kg
• Engine：Nissan
• Wheel Base：1700mm
• Color：Decided by Buyer
• Overall Length(Without Fork)：2720mm
• Rated Power：51kw,2300rpm
• Free Lift：150mm
• Ground Clearance：135mm
• Item：High Quality Forklift Type
• Transport Package：Container
• Specification：2720mm*1285mm*2140mm
• Trademark：LTMG
• Origin：China
• HS Code：8427209000
• Production Capacity：800sets,Year

Manufacturer  LTMGModel Power shift T/MFG35Manual shift T/MFG35Load capacity kg3500Load center mm500Power unit  GasolineOperator type  Driver/seatTire typeFront/rear PneumaticWheelFront/rear 2/2Max. lifting height mm3000Free lift mm150Fork sizeL*W*Tmm1070*125*50Tilt rangeMast forward/backwarddeg6/12Overall length(without fork) mm2720Total width mm1285Mast height (fork lowering) mm2075Overall height fork raisedWith backrestmm4250Height to head guard mm2140Turning radius(outside) mm2460Front face of fork to front axle mm485Min. right angle stacking aisle  without load length&clearancemm2940SpeedMax Travelling full/no loadkm/h18/19.5Lifting full/no loadmm/s450/500Lowering full/no load mm/s450/420Max.drawbar pullPower shift T/M full/no loadkg1800/1000Manual shift T/M full/no loadkg1900/1000Gradeability at 1.6km/hPower shift T/M full/no load%17/20Manual shift T/M full/no load%17/20Truck weight kg4610Weight  distributionFull load front/rearkg7260/850No load front/rearkg1840/2770TiresNumberfront/rear2/2Modelfront axle28x9-15-12PRrear axle6.50-10-10PRWheelbase mm1700TreadFront/rearmm1060/970Ground clearanceAt lowest point(mast)mm120Framemm135BrakeService  brake Hydraulic-foot pedalParking brake Mechanical-hand leverBatteryVoltage/capacityV/AH12/60EngineModel Nissan K25Rated powerPS(kw/rpm)51/2300(37.4/2300)Rated torquekg-m    max.(N.m)18/1600(177/1600)Number of cylinders 4PlacementL2.488Fuel tank capacityL70TransmissionSpeed forward/backwardPower shift T/M Manual shift T/M1-1 power shift T/M 2-2 power shift T/MOperating pressureHydraulic system pressurekg/cm²180
Product Features

1.Safe:
LED work lights and warning lights make it safer and more efficient evenin poor lighting conditions.
New designed overhead guard protective device prevent the sudden accidents.
Thicker reinforcing plate ensure the safety and efficiency.

2.Easy to operate:
Linde-Technology single chain with reinforced load backrest--makes an excellent and wider field of visionfor operator.

3.Beautiful and comfortable:
New suspension adjustable seat makes the long time operating more comfortable.
Step area is 1.5 times larger with lower step height than fellow forklifts.

4.Durable:
Sunken tilt cylinder under the floor build broader flat floor and less abrasion.
Change plastic slider to alloy copper slider, reduce the abrasion and narrow the gap between masts.
Thicker steering axle bridge deck.

5.Environmental:
Middle muffler, more environmental.

6.High technology:
Maintenance free radiators adopt Germany technology.

After sales service
LTMG always treat after-sale service more important than sale.
Nowadays more than 30 agents around the world can supply LTMG professional after-sale service.
All the product of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
Detail clauses and policies please check our website and product certificate.



LTMG Factory


Our Customer


FAQ

1.What's the Certificate do you have?
LTMG workshop meet with the ISO9001:2008 Quality System.
All of our products with CE certificate.  Some of our products meets the EPA requirements.
LTMG neverrecruit Underage labor.

2. Can you customize and design as the clients' requirement?
LTMG will try its best to meet all kinds of clients' special requirements.
However, All the customizing and refit should be implemented safely and scientifically.
The colors can be painted as client's need.

3.How long is the warranty of your products?
Normally 1 year or 2000 working hours whichever occurs first. Details to see the LTMG warranty policy for each model.

4. Can you produce the products labeled with the client's brand?
With the authorization of the brand, we can OEM for our clients.

5. What's the payment terms do you accept?
Normally 30% T/T in advance as deposit, blance paid before shipment.
100% L/C at sight issued by world famous bank with good faith is also available.

6.Delivery time:
Standard configuration products are always in stock.
The production period of Customizing products is from 15 days to 35 days.
