• Model NO.：FL30
• Lift height：3000~5000mm
• Condition：New
• Free Lifting Height：135mm
• Fork Size：1070*125*45mm
• Mast Tilt Angle：6,12 Degree
• Min. Ground Clearance：120mm
• Overhead Guard Height：2090mm
• Front Overhang：475mm
• The Turning Radius：2400mm
• Transport Package：Nude Package
• Trademark：SNSC
• Origin：China
• HS Code：84270290
• Production Capacity：100 Sets Per Month

SpecificationsUnitFL30FeaturesPower type  LP/GasolineRated load kg3000Load center mm500Lifting height mm3000Free lifting height mm145Fork size L*W*Tmm1070*125*45Mast tilt angleFront/RearPerformanceMax. travelling speedloadedkm/h20Max. lifting speedloadedmm/s470Max. traction forceloadedKN18Max. climbing ability %20DimensionOverall lengthwithout forkmm2695Overall width mm1230Mast lowered height mm2055Mast extended height mm4265ChassisTyreFront 28*9-15-12PRRear 6.50-10-10PRWheel base mm1700Wheel threadFront/Rearmm1000/970Weight(without load) kg4350PowertrainBattery V/AH12/90EngineModel nissan K25Rated powerkm/r.p.m37.4/2300Rated torqueNm/r.p.m176.5/1600No. cylinder 4Bore x strokemm89X100Displacement L2.488Fuel tank capacity L70Transmission/shift  1/1 automatic transmissionOperation pressure Mpa17.5
Details of 3Ton LPG Forklift FL30



Forklift Catalogue:
Diesel Forklift capacity is from 1.5 ton diesel forklift to 10 ton diesel forklift;
(FD15/FD20/FD25/FD30/FD35/FD40/FD45/FD50/FD60/FD70/FD80/FD100)
Electric Forklift capacity is from 1.5ton battery forklift to 3.5ton battery forklift;
(FB15/FB20/FB25/FB30/FB35)
LPG&Gasoline Forklift capacity is from 1.5ton LPG forklift to 3.5ton LPG forklift;
(FL15/FL20/FL25/FL30/FL35)
Wearhouse material handling equipments include Electric Pallet Truck (TB)/Electric Stacker(DB)/ Electric Reach Truck(YB)/Electric Tractor(QB).

Company Introduction:
We, SNSC, are top quality forklift manufacture in China, with 130,000 square meters production area, 30,000 units production capacity per year,5000 sets export volume.

We regarde  "Quality product, reasonable price, efficient production time and good after-sale servie" as our tenet."


We are dedicated to providing forklift VIP solution to meet all kinds of work condition  which means SNSC forklift can be customized.

Your satisfaction is our ultimate goal, SNSC beyond your needs.

We hope to cooperate with more customers for mutual development and benifits. Welcome to contact us with your demands.
