Capacity 7 Tons Forklift Diesel Truck with Side Shift
HECHA INTELLIGENT EQUIPMENT CO., LTD.- Type：Powered Pallet Truck
- Power：Diesel Engine
- Load Capacity：5T - 10T
- Fuel：Diesel
- Load center：500mm
- Lift height：3000~5000mm
Base Info
- Model NO.：FD70
- Condition：New
- Colour：Red
- Transport Package：International Standed Packing
- Specification：FD70
- Trademark：HECHA
- Origin：China
- HS Code：8427109000
- Production Capacity：150PCS,Month
Description
H2007 series 2.0-3.5T diesel forklift specificationGeneral 1 Model FD20T-HGB3 FD25T-HGB3 FD30T-HGB3 FD35T-HGF3 (FD20-HGB1) (FD25-HGB1) (FD30-HGB1) (FD35-HGF1) 4 Power type Diesel 2 Rated capacity kg 2000 2500 3000 3500 3 Load center mm 500 5 Operator type Seated 6 Tyre type Front/Rear pneumatic 7 Number of wheels(X=driven)) Front/Rear 2×/2 Dimens ions 8 Lifting height mm 3000 9 Free lift height mm 140 145 150 10 Fork size LxWxT mm 920×122 ×40 1070×122 ×40 1070×125 ×45 1070×130 ×45 11 Mast tilt range F/R 6/12 12 Overall Length(Without fork) mm 2513 2583 2698 2725 13 Overall width mm 1150 1225 1225 14 Mast lowered height mm 1995 2070 2160 15 Mast extended height mm 4030 4250 3290 16 Overhead guard height mm 2070 2090
