• Model NO.：FD30
• Fuel：Diesel
• Load center：>500mm
• Lift height：3000~5000mm
• Condition：New
• Lifting Height：3000mm
• Fork Size：1.07m
• Wheelbase：1400mm
• Ground Clearance：110mm
• Engine：Quanchai,Isuzu,Xinchai,Mitsubishi
• Transport Package：Container Roro Bulk Break Shipment
• Specification：black
• Trademark：Heli
• Origin：Shanghai
• HS Code：8427109000
• Production Capacity：50PCS,Month

SpecificationsunitFD30R(H)FD35R(H)CharacteristicsPower-dieseldieselRated Capacitykg30003500Center of loadJ(mm)500500Lifting heighth1(mm)30003000Free lifting heighth3(mm)145145Forks L×W×HL5xWxT(mm)1070x125x451070x125x50Tilt Forward/Backwardº6/126/12Min.turning radiusR1(mm)26202660Min.ground clearance(Mast)m(mm)115115Overhead guard heighth4(mm)22002200Height from seat to overhead guardL3(mm)480485Front overhangL4(mm)600650PerfMax.traveling speed(loaded)km/h2020Max.lifting speed(loaded/empty)mm/s470/520470/520Drawbar pull/GradeabilitykN/%18/2018/20DimensionsOverall length (without fork)L1(mm)38503900Overall widthW1(mm)12301230Mast lowered height h2(mm)20752075Mast extended heightmm42604260ChassisTireFront-28x9-15-12PR28x9-15-12PRRear-6.50-10-10PR6.50-10-10PRWheelbaseL2(mm)17001700Tread widthFront/RearS/P(mm)1000/9701000/970Curb weightNone-loadkg43504700PowertrainBatteryVoltage/CapacityV/Ah12/9012/90EngineModel-XC490BPGXC490BPGRated powerkw/r.p.m37/265037/2650Rated torqueN.m/r.p.m148/2000148/2000Cylinder amount-44Bore×Stroke mm90x10090x100DisplacementL2.542.54Fuel tankL6666Transmission-1/1 automatic transmissionWorking pressureMPa1717

Contact








Our company
We, Newindu E-Commerce (Shanghai) Co., Ltd, are professional in construction machinery for nearlly 10 years,exporting with good quality and low price, having excavator,truck crane,bulldozer,wheel loader,motor grader,drilling rig,dump truck,road roller,forklift,reach stacker,and also including the spare parts,etc.
