• Model NO.：FD30
• Lift height：3000~5000mm
• Condition：New
• Model Number：Fd30
• Rated Loading Capacity：3000kg
• Max. Lifting Height：3000mm
• Min. Lifting Height：390mm
• Fork Length：1220mm
• Fork Width：150mm
• Self Weight (Kg)：3900
• Turning Radius：2460mm
• Track Width：1000mm
• Tire：6.5-10-10pr
• Transport Package：Nude
• Specification：40CBM
• Trademark：CHINA
• Origin：Shandong
• Production Capacity：5000

BrandLONKINGGeneral1ModelFD302Rated capacity3000kg3Load center500mm4Power typeGasoline/LPG5TransmissionHydraulicDimensions6Lifting height (H1)3000mm7Free lifting height80mm8Min. turning radius2500mm9Overall length (including fork) (A)3800mm10Overall width (B)1230mm11Overall height (mast lowered) (H)2110mm12Overall height (mast raised) (H2)4270mm13Overall height (overhead guard) (H3)2110mm14Fork length (A3)1220mm15Fork width (B3)125mm16Fork thickness (H4)45mmPerformance17Max driving speed (with/without load)18/20km/h18Max lifting speed (with load)400mm/s19Max traction (with/without load)15.5/10.5kn20Gradeability (with/without load)15/20%21Tilting angles (forward/backward) (α/β)6/12°22Total weight4320kgEngine23Engine modelXINCHAI24Power31kw25Rated speed2800rpm26Displacement2.237L27No. of cylinder4Wheel28Front overhang (A1)465mm29Wheel base (A2)1700mm30Front tread (B1)1000mm31Rear tread (B2)970mm32Front tire28x9-1533Rear tire6.5-10

Photos:

1.. Which countries do we export to?
Asia: Philippine,Vietnam, India, Indonesia, Pakistan, Kazakhstan, Uzbekistan, etc.
Europe: Russia, Belarus, Ukraine, Lithuania, Saudi Arabia, etc.
South America: Brazil, Chile, Paraguay, Argentina, etc.
Africa: South Africa, Ethiopia, Libya, Ghana,Algeria,Nigeria,Congo,Kenya,etc

2.What are our advantages compared with other manufacturers/factories?
1)Reliable Quality: Carefully select regular manufacturers for supporting spare parts
,like engines,bridge,transmissions,and many parts designed and produced by ourselves,
always adapting the best materials.
2)Competitive Price: Concentration of mechanized production in large quantities reduce
production cost to ensure that our price is competitive.
3)Service Team: First, our sales managers are online 24 hours,ready to answer your
questions at any time. Second, professional maintenance team with senior technicians,
ready to provide support services to users and dealers. Most problems can be solved
within 24 hours.
4)Fast Delivery:Under normal circumstances,we can delivery with 10 working days in
factory after receiving pre-payment.
3.Which payment terms can we accept?
Normally we can work on T/T or L/C.
1)On T/T term, 30% payment is required in advance for production, 70% balance shall
be paid before delivery or against the copy of original B/L for old long cooperation clients.
2)On L/C term, 100% irrevocable L/C at sight without "soft clauses" can be accepted.
4. How long is the validity of our quotation?
As a reliable supplier, basically our price remains stable through one year, we only adjust
our price based on two situations:
1)The rate of USD
2)TheThe price of material

Other questions, please contact me directly!!
