China Factory Mima Battery Powered Electric Forklift Truck 4500kgs
Banyitong Science & Technology Developing Co., Ltd.- Cab Location：Not Adjustable
- Type：Electric Forklift
- Power：AC Motor
- Load Capacity：1T - 5T
- Fuel：Electric
- Load center：500mm
Base Info
- Lift height：>5000mm
- Condition：New
- Controller Brand：Curtis
- Certificate：Ce
- Power Type：Battery
- Operate Type：Seat
- Rated Capacity：5000kg
- Lift Motor Type：DC
- Drive Motor：AC Motor
- Brand：Mima
- Color：Red
- Lifting Height：6000mm
- Transport Package：Standard Packing
- Specification：ISO9001
- Trademark：MIMA
- Origin：Hefei
- HS Code：84271090
- Production Capacity：1000 Units,Year
Description
Model No. MK40 MK45 MK50 Standard Power type Battery Battery Battery Operate type Seated Seated Seated Rated capacity Q(kg) 4000 4500 5000 Load center C(mm) 500 500 500 Wheel Wheel type Solid rubber tire Loading wheel 18×7-8 21×8-9 21×8-9 Driving wheel 23×10-12 250-15 250-15 Wheel tread, drive side 1080 1225 1225 Wheel tread, load side 990 1025 1025 Number of wheels. -front/rear (X=Drive wheel) 2X / 2 2X / 2 2X / 2 Dimension Mast tilting α/β(º) 6/11 6/11 6/11 Lift height h1(mm) 3000 3000 3000 Free lift height h2(mm) / / / Mast closed height h3(mm) 2100 2180 2180 Mat extended height h4(mm) 4256 4040 4040 Overhead guard height h6(mm) 2130 2250 2250 Mast ground clearance h8(mm) 90 120 120 Overall length 11(mm) 3770 4060 4060 Length to fork face 12(mm) 2700 2990 2990 Wheelbase y(mm) 1800 2000 2000 Front overhang x(mm) 484 530 530 Overall width b1/b2(mm) 1330 1470/1350 1470/1350 Fork dimensions mm 1070*125*50 1070*150*50 1070*150*50 Fork outside width b5(mm) 250-1050 320-1320 320-1320 Trurning radius Wa(mm) 2450 2690 2690 Function Driving speed, lode/unload km/h 12/13 12/13 12/13 Max. gradeability -load/unload % 14/15 15/15 15/15 Driving motor (S2-60min) kw AC14 AC16.6 AC16.6 Lift motor type DC AC AC Lift motor (S3-15%) kw 10 15 15 Battery voltage/capacity V/AH 80/450 80/560 80/630 Weight Battery weight kg 1195 1390 1690 Service weight kg 5300 6800 7100 Steering Steering type Full hydraulic Parking Brake model Hydraulic power Parking Operation type Pedal
Why choose us
BANYITONG SCIENCE & TECHNOLOGY DEVELOPING CO., LTD.
Founded in 1994, BANYITONG SCIENCE & TECHNOLOGY DEVELOPING CO.,LTD is located in Hefei, Eastern of China. As the leading manufacturer of Chinese electric forklift and material handling equipment, we are specialized in designing and developing with all-around logistics handling solutions. We have passed not only ISO9001:2008, ISO14001:2004 and CE certifications, but also got the People's Republic of China Special Equipment Production License and the honor of "Innovative Enterprise".
Referring to 12 series and more than 50 kinds of products, MiMA can offer you with electric forklift, electric reach truck, pallet stacker, pallet truck, order picker, tow tractor, narrow aisle forklift, special forklift, AGV and other customized equipments, which can provide customers with logistics handling solutions from 500kg to 100,000kg. Due to serialization and standardization, all MiMA products are widely used in medicine, food, chemical, household electrical appliances, wool cotton textile, tobacco, electronics, machinery, furniture and many other industries.
As our logo, MiMA has the deep meaning: "Minimum Space, Maximum Benefit", we believe that urban logistics is a mega trend, that needs new, smart and saving space solutions, we have those solutions already today.
Owing to 100 national service networks and dozens of foreign dealers, we promise customers with competitive prices and perfect after-sales service.
Our workshop and warehouse
Many of our models are in stock, for more details please feel free to contact us.
Exhibition
Why choose us
BANYITONG SCIENCE & TECHNOLOGY DEVELOPING CO., LTD.
Founded in 1994, BANYITONG SCIENCE & TECHNOLOGY DEVELOPING CO.,LTD is located in Hefei, Eastern of China. As the leading manufacturer of Chinese electric forklift and material handling equipment, we are specialized in designing and developing with all-around logistics handling solutions. We have passed not only ISO9001:2008, ISO14001:2004 and CE certifications, but also got the People's Republic of China Special Equipment Production License and the honor of "Innovative Enterprise".
Referring to 12 series and more than 50 kinds of products, MiMA can offer you with electric forklift, electric reach truck, pallet stacker, pallet truck, order picker, tow tractor, narrow aisle forklift, special forklift, AGV and other customized equipments, which can provide customers with logistics handling solutions from 500kg to 100,000kg. Due to serialization and standardization, all MiMA products are widely used in medicine, food, chemical, household electrical appliances, wool cotton textile, tobacco, electronics, machinery, furniture and many other industries.
As our logo, MiMA has the deep meaning: "Minimum Space, Maximum Benefit", we believe that urban logistics is a mega trend, that needs new, smart and saving space solutions, we have those solutions already today.
Owing to 100 national service networks and dozens of foreign dealers, we promise customers with competitive prices and perfect after-sales service.
Our workshop and warehouse
Many of our models are in stock, for more details please feel free to contact us.
Exhibition
