• Model NO.：FB30
• Load center：500mm
• Lift height：3000~5000mm
• Condition：New
• Fork Size：1070mm*125mm*45mm
• Wheelbase：1600mm
• Weight：4660kg
• Color：Could Be Designed by Buyer
• Max. Lifting Height：3000mm
• Overall Length(Without Fork)：2510mm
• Tire Type：Pneumatic
• Total Width：1225mm
• Optional：Side Shift, Three Stage Mast, Solid Tires
• Transport Package：Nude Packing, Fixed in Container
• Specification：2510mm*1225mm*2190mm
• Trademark：LTMG
• Origin：China
• HS Code：8427109000
• Production Capacity：800sets,Year

Manufacturer   LTMGModel     FB30Load capacity    kg3000Load center mm500Power unit   BatteryOperator type   Driver/seat         Tire type   Pneumatic                  Wheel(x=driving)  Front/rear 2X/2Max. lifting height    mm3000Free lift    mm165Fork size L*W*Tmm1070*125*45Tilt range     Mast forward/backward deg6/12Overall length(without fork)  mm2510Total width  mm1225Mast height (fork lowering) mm2075Overall height fork raised With backrest mm4250Height to head guard mm2190Turning radius(outside) mm2140Load distance mm480Min. right angle stacking aisle not add load length&clearancemm2625Speed  Max Travellingfull load km/h13.5Max Travellingno loadkm/h15Liftingfull load mm/s240Liftingno load mm/s450Gradeability    full loa%12.5Truck weight(with standard battery) kg4660Weight  distribution Fullloadfront/rear  kg6770/890Noloadfront/rear kg1885/2775TiresNumber           front/rear  2/2Model  front axle  28*9-15-12PRrear axle18*7-8-14PRWheelbase  mm1600Tread    Front/rearmm1000/950Ground clearance  At lowest point(mast)mm140Frame mm120Brake Service brake   Hydraulic-foot pedal  Parking brake Mechanical-hand lever  BatteryVoltage/capacity  V/AH/5hr72V-480Weight with box (standard)kg 1220Electric motor    AC Driving motor  kw16.6DC Hydraulic driving motor  kw10 AC Hydraulic driving motor (as option)kw13.4Control type Driving AC  , lifting DC
Driving AC  , lifting AC
(as option ) Operating pressure kg/cm²175
Product Features

Equipped with original imported American Curtis electric control system; High voltage and large capacity battery can supply the forklift with strong power.
This electric forklift truck not only has excellent operability, comfortable and safe, and reliable performance with waterproof.
It won't be emissions, and does not produce noise.
All the parts of reasonable design, combined with a series of designed to increase productivity power regeneration function, to achieve the goal of control power consumption.
LTMG forklift trucks are designed for the operator to be more productive and require less downtime for maintenance.

After sales service
Nowadays more than 100 agents around the world can supply LTMG professional after-sale service.
All the product of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
Detail clauses and policies please check our website and product certificate.
