10 Ton All Wheel Drive Forklift
Qingzhou Welift Machinery Co., Ltd.- Type：Powered Pallet Truck
- Power：Diesel Engine
- Load Capacity：5T - 10T
- Fuel：Diesel
- Load center：>500mm
- Lift height：3000~5000mm
Base Info
- Model NO.：CPCY100
- Condition：New
- Lifting Power：10000kg
- Engine：Deutz, Faw, Cummins Optionally
- Drive Type：Full Wheel Drive
- Cabin：Side Turn for Easy Repair
- Controller：Joystick
- Transport Package：40hq 1set
- Specification：CE BV certificates; ISO quality system verify
- Trademark：SWLTD
- Origin：Qingzhou City, Shandong Province, China
- HS Code：84272090
- Production Capacity：3000 PCS Per Year
Description
The main parameters CPCY100No item
unit
standard model
optional model1 Limit load KG 10000 10000 2 length No fork MM 5425 5425 Belt fork MM 6650 6650 3 width MM 2620 2620 4 height Door frame height MM 3035 3035 Height bridge MM 3400 3400 When maximum lifting height MM 4430 5880 5 wheelbase MM 2745 2745 6 Before hanging distance MM 930 930 7 Front wheel tread MM 1850 1850 8 Wheel track after MM 1805 1805 9 Ground clearance MM 390 390 10 Maximum lifting height MM 3000 4500 11 The door frame top rake/door frame caster Angle (° ) 6/12 6/12 12 Standard no load state of the overall quality KG 14500 13 Load maximum lifting speed MM/s 187 187 14 minimum turning radius MM 5500 5500 15 With its maximum speed KM/H 24 24 16 Gradeability % 20 20 17 Load maximum traction hook KN 75.0 75.0 18 Load center distance MM 600 600 19 Engine model ---- Deutz WP6G125E22 Deutz WP6G125E22
