• Model NO.：FD40
• Lift height：3000~5000mm
• Condition：New
• Fork Size：1070*150*50mm
• Weight：5050kg
• Engine：Isuzu , Xinchai
• Wheelbase：1700mm
• Color：Decided by Buyer
• Service Brake：Hydraulic
• Overall Length(Without Fork) ：2870mm
• Rated Power：44.8kw,2450rpm
• Tire Type：Pneumatic
• Optional：Fork Position, Cab, AC, Solid Tyres, etc
• Transport Package：Container
• Specification：2870mm*1365mm*2140mm
• Trademark：LTMG
• Origin：China
• HS Code：8427209000
• Production Capacity：500sets,Month

The specification of 4 ton Diesel ForkliftManufacturer     LTMGModel Power shift T/M  FD40Load capacity    kg4000Load center  mm500Power unit   Diesel  Operator type   Driver/seatTire type  Pneumatic Wheel Front/rear 2/2Max. lifting height mm3000Free lift  mm150Fork size                 L*W*Tmm1070*150*50Tilt range                       Mast forward/backwarddeg6/12Overall length(without fork)     mm2870Total width  mm1365Mast height (fork lowering)   mm2150Overall height fork raised     With backrest mm4250Height to head guard             mm2140Turning radius(outside)          mm2530Front face of fork to front axle mm485Min. right angle stacking aisle
without load length&clearance  mm2940Speed Max Travelling    full/no loadkm/h16.5/18Lifting      full/no loadmm/s380/480Lowering    full/no loadmm/s450/420Max.drawbar pull         Power shift T/M      full/no loadkg2200/1000Manual shift T/M    full/no loadkg2200/1000Gradeability at 1.6km/h       Power shift T/M      full/no load%18/20Manual shift T/M    full/no load%18/20Truck weight kg5050Weight  distribution   Full  load              front/rear    kg7890/1140No  load               front/rear     kg1810/3240Tires  Numberfront/rear2/2Modelfront axle 250-15-16PRrear axle6.50-10-10PRWheelbase  mm1800Tread           Front/rearmm1120/970Ground clearance At lowest point(mast)                mm120Framemm135Brake      Service  brake Hydraulic-foot pedalParking brake Mechanical-hand lever   BatteryVoltage/capacityV/AH12/80Engine   Model ISUZU 4JG2Rated powerkw/rpm44.8/2450Rated torqueN.m/rpm186/1800Number of cylinders 4PlacementL3.059Fuel tank capacityL70Transmission Speed forward/backward Power shift T/M       Manual shift T/M1-1 power shift T/M
2-2 manual shift T/MOperating pressureHydraulic system pressure  kg/cm²180
